Configuration #1 (Local EIA-232 to Remote EIA-232)

ASYNC TX and RX Type
ASYNC TX and RX Baud Rate
ASYNC TX and RX Length
ASYNC TX and RX Parity
ASYNC TX Stop
ASYNC TX and RX Type
ASYNC TX and RX Baud Rate
ASYNC TX and RX Length
ASYNC TX and RX Parity
ASYNC TX Stop
Remote Baud Rate
Parity
Address
The local end cable connects the 25-pin female ASYNC connector (on either the
breakout panel or the Y cable) to the EIA-232 remote terminal (WYSE or laptop
computer). The pinout of the local cable is listed in the following table.
The remote end cable connects the 25-pin female ASYNC connector (on either the
breakout panel or the Y cable) to the 9-pin female connector, J6, at the rear of the
modem. The pinout of the remote cable is listed in the following table.
A–30

Table A-5. Local EIA-232 to Remote EIA-232

#1. Local End Modem Settings for EIA-232
Utility Interface Menu
EIA-232
Configuration Interface Menu
150 to 38400
7 bits
Even
2 bits
#1. Remote End Modem Settings for EIA-232
Utility Interface Menu
EIA-232
Configuration Interface Menu
150 to 38400
7 bits
Even
2 bits
Utility System Menu
Equal to ASYNC TX and RX baud rate
Even
1 to 255
#1. Local End EIA-232
9-Pin
Female Connector
RX 2
TX 3
GND 5
#1. Remote End EIA-232
9-Pin
Male Connector
RX 2
TX 3
GND 5
(See A.1.4.3.10)
(See A.1.4.3.10)
25-Pin
Male Connector
3 TX
2 RX
7 GND
25-Pin
Male Connector
2 RX
3 TX
7 GND
