Comtech EF Data SDM-300A Installation And Operation Manual page 284

SDM-300A Satellite Modem
Interface Command:
Loopback Response:
Status:
Response:
Interface Command:
Loop Response:
Timing
Status:
Response:
Interface
Buffer Size
Interface Command:
Buffer Size Response:
(Bit Format)
Status:
Response:
Interface Command:
Buffer Size Response:
(Milli-
second Status:
Format) Response:
Interface Command:
Buffer Response:
Center
Interface Command:
Buffer Response:
Program-
ming Status:
Response:
Interface Command:
Receive Response:
Farming
Structure Status:
Response:
Interface Command:
Substitute Response:
Pattern
Status:
Response:
Interface Command:
Read Error Response:
Select
Status:
Response:
Rev. 4
<add/ILB_xxx'cr'
>add/ILB_xxx'cr''lf']
<add/ILB_'cr'
>add/ILB_xxx'cr''lf']
<add/ILT_xxx'cr'
>add/ILT_xxx'cr''lf']
<add/ILT_'cr'
>add/ILT_xxx'cr''lf']
<add/IBS _nnnnnn'cr'
>add/IBS _nnnnnn'cr''lf']
<add/IBS _'cr'
>add/IBS _nnnnnn'cr''lf']
<add/IBS _nn'cr'
>add/IBS _nn'cr''lf']
<add/IBS _'cr'
>add/IBS _nn'cr''lf']
<add/IBC_'cr'
>add/IBC_'cr''lf']
<add/IBP_xxxx'cr'
>add/IBP_xxxx'cr''lf']
<add/IBP_'cr'
>add/IBP_xxxx'cr''lf']
<add/IRFS_ff_ssss'cr'
>add/IRFS_ff_ssss'cr''lf']
<add/IRFS_ff'cr'
>add/IRFS_ff_ssss'cr''lf']
<add/ISP_xxxxxx'cr'
>add/ISP_xxxxxx'cr''lf']
<add/ISP_'cr'
>add/ISP_xxxxxx'cr''lf']
<add/IRE_xxxxxx'cr'
>add/IRE_xxxxxx'cr''lf']
<add/IRE_'cr'
>add/IRE_xxxxxx'cr''lf']
Remote Control Operation
Where: xxx = ON or OFF.
Where: xxx = ON or OFF.
Buffer size programming is supported in two formats; bits,
or milli-seconds. The selected format must be chosen
using the buffer programming command (IBP_). If the
buffer is to be programmed in milli-seconds and
plesiochronous slips are required use the receive framing
structure command (IRFS_) to define the proper framing
format.
Note: For Drop & Insert: Only milli-seconds format is
allowed.
Where: nnnnnn = 32 to 262144, in 16 bit increments.
Where: nn = 0 to 99 (buffer size in milli-seconds).
Note: For Drop & Insert:
1. nn = 7.5, 15, or 30 (milli-seconds) for E1CAS
format.
2. nn = 6, 12, 24, or 30 (milli-seconds) for
T1S/T1ESFS format.
3. nn = 1, 2, 4, 8, 16, or 32 (milli-seconds) for all
other D&I formats.
Where: xxxx = BITS or MS (milli-seconds).
Note: For Drop & Insert: Only milli-seconds format is
allowed.
Where:
ff = T1 or E1 (frame type).
ssss = NONE or G704 (framing structure).
Where: xxxxxx = ON or OFF.
Note: Transmit 2047 Pattern.
Where: xxxxxx = ON or OFF.
Note: Receive 2047 Pattern.
B–9
