DMD50 Universal Satellite Modem
IDR2 SAT CNTRL
IDR3 SAT CNTRL
IDR4 SAT CNTRL
IBS SAT CNTRL
T1E1 TERR CNTRL
IBS TX PROMPT
IBS TX SERVICE

4.4.7 System Menu Options and Parameters

DATE (MM/DD/YY)
TIME {HH:MM:SS}
CONFIG COPY
FRONT PANEL (menu)
BKLT LEVEL
BKLT TIMEOUT
KEY CLICK
MENU NAVIGATION
MN-DMD50– Revision 3
FRC ON: Forces an ON alarm status that is transmitted to the
distant end.
FRC OFF: Forces an OFF alarm status that is transmitted to the
distant end.
{STNDRD, FRC ON, FRC OFF}
{STNDRD, FRC ON, FRC OFF}
{STNDRD, FRC ON, FRC OFF}
{STNDRD, FRC ON, FRC OFF}
{STNDRD, FRC ON}
{STNDRD, FRC ON}
{STNDRD, FRC ON}
Allows the user to enter the current date.
Allows the user to enter the current time.
{Current, CFG1......CFG10}
Allows user to copy, save and recall modem configurations.
{OFF, LOW, MED, HIGH}
Allows the user to enter the backlight intensity level.
{00 - 99}
Allows the user to enter the length of time (in seconds) of
keyboard inactivity before the backlight shuts off. 00 = no
timeout.
{ON, OFF}
Allows the user to enable or disable the audible beep each time a
key is pressed. Illegal entries will still cause a beep to be heard.
{STANDARD, FLOATING}
Standard: This setting has a fixed starting point for all sub-
menus.
Floating: Sub-menus are floating, always returning to the last
menu that was accessed.
User Interfaces
4–32
