SDM-300A Satellite Modem
Bulk Consol.
Status
(continued)
Parameter
Number
(Note 5)
89
(Note 6)
90
(Note 5)
91
(Note 6)
92
(Note 5)
93
(Note 6)
94
(Note 14)
95
(Note 14)
96
(Note 14)
97
(Note 14)
98
(Note 15)
99
(Note 15)
100
(Note 14)
101
(Note 14
102
103
104
105
106
Rev. 4
Parameter Name
(Command Reference)
ASYNC TX Channel Stop
(ref. 'TCSB_' command).
ASYNC RX Channel Stop Bits
(ref. 'RCSB_' command).
ASYNC TX Channel Parity
(ref. 'TOCP_' command).
ASYNC RX Channel Parity
(ref. 'ROCP_' command).
ASYNC TX Communications Type
(ref. 'TCT_' command).
ASYNC RX Communications Type
(ref. 'RCT_' command).
AUPC Local Power enable ON/OFF
(ref. 'LPC_' command).
AUPC Nominal Power Value
(ref. 'NOMP_' command).
AUPC Minimum Power Value
(ref. 'MINP_' command).
AUPC Maximum Power Value
(ref. 'MAXP_' command).
AUPC EBN0 Target Set Point
(ref. 'ENSP_' command).
AUPC Max. Tracking Rate
(ref. 'MAXT_' command).
AUPC Local Carrier Loss
(ref. 'LCL_' command).
AUPC Remote Carrier Loss
(ref. 'RCL_' command).
reserved null field.
reserved null field.
Transmit BPSK Data Ordering
(ref. 'TDA_' command).
Receive BPSK Data Ordering
(ref. 'RDA_' command).
Description
p89 = n, where 'n' is the current number of stop bits
programmed.
p90 = n, where 'n' is the current number of stop bits
programmed.
p91 = xxxx, where 'xxxx' is the currently programmed parity.
p92 = xxxx, where 'xxxx' is the currently programmed parity.
p93 = n, where 'n' is '0' (RS232), '1' (RS485_4WIRE), '2'
(RS485_2WIRE).
p94 = n, where 'n' is '0' (RS232), '1' (RS485).
p95 = n, where 'n' is '0' (off) or '1' (on).
p96 = snn.n, where 'snn.n' Nominal Power Value in dBm.
p97 = snn.n, where 'snn.n' Minimum Power Value in dBm.
p98 = snn.n, where 'snn.n' Maximum Power Value in dBm.
p99 = nn.n, where 'nn.n' EBN0 Target Set Point in dB.
p100 = n.n, where 'n.n' is the Max. Tracking Rate in dB/Min.
p101 = n, where 'n' is '0' (HOLD), '1' (NOMINAL), or '2'
(MAXIMUM).
p102 = n, where 'n' is '0' (HOLD), '1' (NOMINAL), or '2'
(MAXIMUM).
p105 = n, where 'n' is '0' (NRM), '1' (INV).
p106 = n, where 'n' is '0' (NRM), '1' (INV).
Remote Control Operation
B–43
