Dimensional Envelope; Figure 1-5. Dimensional Envelope - Comtech EF Data SDM-300A Installation And Operation Manual

SDM-300A Satellite Modem
1.5

Dimensional Envelope

Refer to Figure 1-5 for the unit's dimensional envelope.
Note: Dimensions are listed in inches and centimeters are in parenthesis.
1.75
(4.4 )
19 .0
(4.8 )
Rev. 4
1.25
(3.2 )
3.0 3.625
(8) (9.2 )

Figure 1-5. Dimensional Envelope

14 .0
(36)
3.625
(9.2 )
