Terrestrial Interface Types

C.7.1

Universal

The following interface types are available through the EIA-530 25-pin data I/O
connector.
•
•
•
Optional mechanical interfaces are also available. See Chapter 2 for pinout information.
•
•
•
The following interface types are available through the optional 50-pin data I/O
connector with overhead card installed. In order to meet the mechanical specification, the
correct break out panel must be connected to the modem.
•
•
•
•
Rev. 4
EIA-232
V.35
EIA-422, MIL-188-114A
37-pin 'D' (EIA-449)
34-pin Block (V.35)
50-pin 'D'
G.703
IDR
IBS
Drop and Insert (G.703)
