SDM-300A Satellite Modem
Change Command:
Status Response:
Equipment Command:
Type Response:
Monitor & Command:
Control Response:
Firmware
Information
DATA ROM Command:
Firmware Response:
Information
Rev. 4
<add/CS_'cr'
>add/CS_x'cr''lf']
<add/ET_'cr'
>add/ET_tttttttt_xxx.yyy.zzz'cr''lf']
<add/MCFI_'cr'
>add/MCFI_'cr'
VER_xxx.yyy.zzz'cr'
FW/nnnnnn-ddr'cr'
mm/dd/yy'cr''lf']
<add/DFI_'cr'
>add/DFI_'cr'
FW/nnnnnn-ddr'cr'
mm/dd/yy'cr''lf']
Character 'p': Interface backward alarm status character 1.
Bit 6 = 1 always.
Bit 5 = TX Backward Alarm 1.
Bit 4 = TX Backward Alarm 2.
Bit 3 through Bit 0 = Binary representation (0 to 10) of
the number of backward alarm stored faults.
Character 'q': Interface backward alarm status character 2.
Bit 6 = 1 always.
Bit 5 = TX Backward Alarm 3.
Bit 4 = TX Backward Alarm 4.
Bit 3 = RX Backward Alarm 1.
Bit 2 = RX Backward Alarm 2.
Bit 1 = RX Backward Alarm 3.
Bit 0 = RX Backward Alarm 4.
Character 'r': Interface Reed-Solomon Unavailable Seconds
Bit 6 = 1 always.
Bit 5 = not used.
Bit 4 = not used.
Bit 3 through Bit 0 = Binary representation (0 to 10) of
the number of Reed-Solomon Unavailable Seconds
stored faults.
Where:
The 'x' character is defined as follows:
'@' = no change since last BCS_ and BCSF_ polls.
'A' = BCS_ response has changed since last BCS_ poll.
'B' = BCSF_ response has changed since last BCSF_
poll.
'C' = Both responses have changed since last BCS_ and
BCSF_ polls.
This command indicates that a change has or has not
occurred on either the BCS_ or the BCSF_ response since
the last BCS_ or BCSF_ poll.
Where:
tttttttt = Equipment type.
xxx.yyy.zzz = Software version.
Where:
xxx.yyy.zzz = Software version number (0.0.0 to
999.999.999).
nnnnnn = Firmware number (0 to 999999).
dd = Firmware dash number (0 to 99).
r = Firmware revision (-, or A to Z).
Where:
nnnnnn = Firmware number (0 to 999999).
dd = Firmware dash number (0 to 99).
r = Firmware revision (-, or A to Z).
Note: If Dash number is not used, '-dd' will be reported.
Remote Control Operation
B–49
