Component Chassis Hardware Specifications

Component Chassis Hardware Specifications
The following tables provide information on the hardware specifications and the
power characteristics of the Pilot, Controller, and Drive Enclosures.
Dimensions and Weight

Table 3: Pilot dimensions and weight

Attribute
Height
Width
Depth (not
including power
supply handles)
Weight

Table 4: Controller dimensions and weight

Attribute
Height
Width
Depth
Weight
Value
1.68 in (4.26 cm)
Server chassis (not including ears): 17.19 in (43.65 cm)
Server chassis (with bezel): 18.9 in (48.24 cm)
29.0 in (73.7 cm)
40 lb (18.1437 kg): Weight of one Pilot.
Value
3.45 in (8.76 cm)
17.52 in (44.55 cm)
20.25 in (51.435 cm)
41 lb (18.59 kg)
