Hummer H1 Service Manual page 939

12-162 Electrical System
42 WAY UNDERBODY LOCATION: LOWER LEFT FOOTWELL NEAR ENGINE
C2 MALE
C2 FEMALE
PIN CKT COLOR
1 43
2 20
3 12
4 13
5 3
6 80
7 2
8 767
9 49
10 996
11 997
12 32
13 33
4-1-00
______________________________________________________
PIN 34
PIN 28
PIN 22
PIN 16
PIN 10
PIN 1
CAV 42
CAV 33
CAV 27
CAV 21
CAV 15
CAV 9
DB Trailer brake activation
RD Front parking lamp feed
OR Headlamp high beam feed
TN Headlamp low beam feed
LB Left front turn signal
WH Underhood lamp power
LG Right front turn signal
BR Compass mirror temperature signal
OR Battery power to trailer connector
BR Left front wheel speed sensor low signal
BK Left front wheel speed sensor high signal
LB Neutral safety switch feed to start relay
WH Neutral safety switch ignition feed
PIN 42
PIN 33
PIN 27
PIN 21
PIN 15
PIN 9
9-S12-015
CAV 34
CAV 28
CAV 22
CAV 16
CAV 10
CAV 1
9-S12-016
DESCRIPTION
®
