Reset
Before running any test, be sure to busy-out or reset the module. Reset discontinues service to all
lines and extensions on the module instantly. In-progress calls are dropped if all of the calling
parties on the call originate and terminate on the module being reset.
If a call is using a line or extension on the module being Reset and another line and/or extension is
involved in the call, the call on the module being reset is put on hold. In this case, a demand test
cannot be performed because the module is not busied out. If you reset a module, be sure to
check the status of that module before performing a demand test.
Busy-out is the preferred method of discontinuing service to a module, because it does
not disrupt calls in progress
Procedure
Appropriate Modules Any module that you are about to test.
Time Estimate
→
Menu
Maintenance
→
Reset Yes
While the module is discontinuing service to the lines/trunks and
extensions, a Reset in Progress message is shown on the screen.
When the module is successfully reset, Reset Complete is displayed. If
the reset fails, Reset FAILED is displayed.
In the procedure above, when you select Enter , the following additional
options appear, depending on the module:
For all MLX modules,
I
For 100D modules, CSU-lpbk , Error Events , and Clock are also
I
displayed.
For all 800 NI-BRI modules, Clock , BChLoopback , and
I
Provisioning are also displayed.
To reset a 100 DCD module, you select each of the two data ports or slots
separately. The system indicates if the reset completed successfully or
failed. When the 100 DCD module is not installed in the carrier, the
maintenance screens do not display the maintenance options to busy-out
the data ports.
Less than 1 second (all calls in progress are terminated or put on hold
immediately). If you do not want to interrupt calls in progress, use Busy-Out
instead of Reset.
6
→ →
Enter the slot no. (01-17)
Slot
is also displayed.
BChLoopback
Tests
→ →
Enter
Busy-Out and Reset
