CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
Rx Demod RSW= RSW?
Acquisition
Sweep Width
Rx Transport RTM= RTM?
Mode
Serial N/A SNO?
Number
Software N/A SWR?
Revision
Real-time TIM= TIM?
Clock Time
Temperature N/A TMP?
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
3 bytes Command or Query.
Sets or returns the Rx ± acquisition sweep range of demodulator in the form
xxx where:
xxx=value in KHz, from ± 1 to 100 kHz.
1 byte Query only.
Returns the transport mode in the form x where:
0=Generic Mode
1=Transport Stream Mode (Default)
NOTE: Query valid only with CDI-60 HSSI operation in DVB-S2 Mode. For any
other mode, RTM reports as RTM=1.
EXAMPLE: <0001/RTM?{CR}
>0001/RTM=1 (reports Transport Stream selected)
9 bytes Query only.
Returns the unit 9-digit serial number in the form xxxxxxxxx.
5 bytes Query only.
Returns the revision numbers of the installed firmware, in the form:
Boot:X.X.X Bulk1:Y.Y.Y Bulk2: Z.Z.Z
EXAMPLE: <0001/SWR1?{CR}
>0000/SWR=Boot:1.0.3 Bulk1:1.0.1 Bulk2:1.0.0{CR}{LF}
6 bytes Command or Query.
Sets or returns the time, from midnight, in the form hhmmss where:
hh=hours (00 to 23)
mm=minutes (00 to 59)
ss=seconds (00 to 59)
COMMAND EXAMPLE: <0001/TIM=231255{CR} (sets time to 11:12:55 PM)
3 bytes Query only.
Returns the value of the internal temperature (degrees C), in the form sxxx
where:
s=sign (+/-)
xxx= temperature in degrees C
EXAMPLE: <0001/TMP>{CR}
>0001/TMP=+026{CR}{LF} (reports temperature as 26°C)
9–67
Description of Arguments
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
RSW= RSW=xxx
RSW?
RSW*
RSW#
RTM? RTM=x
RTM*
RTM#
SNO? SNO=xxxxxxxxx
SNO*
SNO#
SWR? SWR=Boot:X.X.X
SWR* Bulk1:Y.Y.Y
SWR# Bulk2:Z.Z.Z
TIM= TIM=hhmmss
TIM?
TIM*
TIM#
TMP? TMP=sxxx
TMP*
TMP#
