CDM-710/L Broadcast Satellite Modem
Front Panel Operation
Option Number
(top line)
07 Tx QPSK
08
Tx 8PSK
09 Tx 16-QAM
10 Tx 16APSK
11 Tx 32 APSK
12 Rx QPSK
13 Rx 8PSK
14
Rx 16QAM
15 Rx 16APSK
16 Rx 32 APSK
17 Tx <=15.0 MS
18 Tx <=22.5 MS
19 Tx <=30.0 MS
20 Tx <=37.5 MS
21 Tx <=45.0 MS
22 Rx <=15.0 MS
23 Rx <=22.5 MS
24
Rx <=30.0 MS
25 Rx <=37.5 MS
26 Rx <=45.0 MS
27 Tx DVB-S1
28 Tx DVB-S2
29
Tx DVB-DSNG
30 Rx DVB-S1
31 Rx DVB-S2
32 Rx DVB-DSNG
Description (bottom line)
