CDM-710/L Broadcast Satellite Modem
Front Panel Operation
(CONFIG:) Intfc2 Gigabit Ethernet:  Ingress  Str  Pri
Use the   arrow keys to select 1 (Single) or 2 (Redundancy) Mode, Press
ENTER. Note that:
• Single mode assigns which (of up to two) stream(s) to process.
• Redundancy mode identifies which of the two streams is initially
processed before any redundancy switch takes place.
(CONFIG:) Intfc2 Gigabit Ethernet:  Ingress  Str  Red
Use the   arrow keys to select Revertive or Non-Revertive. Press ENTER.
Note that:
• In Revertive Redundancy mode, either stream can be processed in the
event of the failure of the other stream.
• In Non-Revertive Redundancy mode, a switch can occur from the
primary stream to the secondary stream, but a switch from the
secondary stream to the primary stream will not occur in the event of a
failure of the secondary stream. The latter case will require user
intervention.
(CONFIG:) Intfc2 Gigabit Ethernet:  Ingress  Str  Timeout
For use in Dual Stream Mode only: Use the ▲▼ arrow keys to assign the period
(in 100 mS steps) for a primary connection failure to be present before
switchover to the secondary connection occurs. Press ENTER.
Intfc2 Primary Stream
1 2
Intfc2 Redundancy
Revertive Non-Revertive
Intfc2 Stream Timeout
0500 mS
7–41
MN/CDM710.IOM
Revision 12
