Comtech EF Data CDM-710 Installation And Operation Manual page 267

CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
Firmware N/A FRW?i
Revisions
GBEI Egress GEF= GEF?
FEC Enable
GBEI Egress GEG= GEG?
Multicast
Group
Address
GBEI Egress GEP= GEP?s
Port Numbers
GBEI Egress GFM= GFM?s
FEC Matrix
GBEI FEC GFP= GFP?
Base Port
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
1 byte Query only.
Returns the firmware information of the system:
i=Bulk Image number (1 or 2)
a=Firmware Image
b=Firmware Revision
c=Firmware Date
2 bytes Command or Query.
Sets or returns CDI-70 GBEI Egress FEC operation in the form sn, where:
s=2 (Interface Slot 2 only)
n=Disable/enable, where 0=Disabled, 1=Enabled
16 bytes Command or Query.
Sets or returns the CDI-70 GBEI Egress Multicast Group Address. The multicast
stream egressing from the CDI-70 GBEI will have this IP address as the source
IP address in the form sxxx.xxx.xxx.xxx, where:
s=2 (Interface Slot 2 only)
xxx.xxx.xxx.xxx=IP Address
11 bytes Command or Query.
Sets or returns the CDI-70 GBEI Egress Port Numbers in the form
snnnnnppppp, where:
s=2 (Interface Slot 2 only)
nnnnn = Source Port Number, value in the range from 0 to 65535
ppppp = Destination Port Number, vale in the range from 0 to 65535
NOTE: Both Source Port and Destination Port must be valid for set command
to take effect.
11 bytes Command or Query.
Sets or returns the CDI-70 GBEI Egress FEC Matrix in the form sll,dd where:
s=2 (Interface Slot 2 only)
ll = Length, two digit number (leading zero) from 1 to 20.
dd = Depth, two digit number (leading zero) from 4 to 20.
NOTE: Length x Depth must be (less than or equal to) ≤100
6 bytes Command or Query.
Sets or returns the CDI-70 GBEI Base Port number in the form snnnnn, where:
s=2 (Interface Slot 2 only)
n=Port Number (0 to 65535)
9–59
Description of Arguments
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
FRW? FRW={CR}Boot:{
FRW* CR}a,b,c{CR}Bul
FRW# ki:{CR}a,b,c{CR}
a,b,c...
GEF= GEF=sn
GEF#
GEF?
GEF*
GEG= GEG=sxxx.xxx.xx
GEG# x.xxx
GEG?
GEG*
GEP= GEP=snnnnnppp
GEP# pp
GEP?
GEP*
GFM= GFM=sll,dd
GFM #
GFM?
GFM*
GFP= GFP=snnnnn
GFP#
GFP?
GFP*
