Comtech EF Data CDM-710 Installation And Operation Manual page 228

CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
Local/Remote LRS= LRS?
Status
Unit MAC N/A MAC?
Address
Unit Alarm MSK= MSK?
Mask
Number of N/A NUE?
Unread
Stored Events
Soft Reboot RBT=1 N/A
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
1 byte Command or Query.
Sets or returns the Local/Remote operation in the form x, where:
0=Local
1=Serial
2=Reserved
3=Ethernet
4=Serial+Ethernet
COMMAND EXAMPLE: <0001/LRS=4 (sets Serial+Ethernet remote mode)
12 bytes Query only.
Returns the MAC address for the unit, in hexadecimal format, in the form
AABBCCDDEEFF.
EXAMPLE: <0001/MAC?{CR}
>0001/MAC=006B000D2A7{CR}{CR}{LF} (The unit MAC Address is
00:06:B0:00:D2:A7)
13 bytes Command or Query.
Sets or returns reporting conditions in the form ab, where:
a=Tx AIS, where 0=Alarm, 1=Fault, 2=Masked
b=spare
COMMAND EXAMPLE: <0001/MSK=00{CR}
3 bytes Query only.
Returns the number of stored events that have not yet been read over the
remote interface in the form xxx.
EXAMPLE: <0001/NUE?{CR}
>0000/NUE=126{CR}{LF}
1 byte Command only.
Executes a soft reboot of the unit in the form x where:
1=Reboot System
EXAMPLE: <0001/RET=1{CR}
9–20
Description of Arguments
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
LRS= LRS=x
LRS?
LRS*
LRS#
MAC? MAC=AABBCCDD
MAC* EEFF
MAC#
MSK= MSK=ab
MSK?
MSK*
MSK#
NUE? NUE=xxx
NUE*
NUE#
RBT? RBTError!
RBT* Bookmark not
RBT# defined.=x
