CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
Initialize IEP= N/A
Events
Pointer
Boot Image IMG= IMG?
Tx Output IMP= IMP?
Impedance
Management IPA= IPA?
IP Address
Gateway IP IPG= IPG?
Address
Interface N/A ITF?s
Type
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
None Command only.
THIS COMMAND TAKES NO ARGUMENTS.
Resets the internal pointer to allow RNE? queries to start at the beginning of
the stored events log.
EXAMPLE: <0001/IEP={CR} (resets stored events log internal pointer)
1 byte Command only.
Selects the Boot image in the form n where:
n=FW Image 1 or 2
COMMAND EXAMPLE: <0001/IMG=1{CR} (sets Image 1 for bootup)
1 byte (CDM-710 70/140 MHz UNIT ONLY)
Command or Query.
Sets or returns the Tx output impedance in the form x where:
0=50 Ohm
1=75 Ohm
COMMAND EXAMPLE: <0001/IMP=0{CR} (sets impedance as 50 Ohms)
18 bytes Command or Query.
Sets or returns the IP Address and Subnet Mask for the 10/100 BaseT 'J4 |
Ethernet' management port, in the form xxx.xxx.xxx.xxx.yy where:
xxx.xxx.xxx.xxx=IP Address
yy=Subnet Mask (00 to 31)
COMMAND EXAMPLE: <0001/IPA=010.006.030.001.24{CR}
15 bytes Command or Query.
Sets or returns the Gateway IP Address for the 10/100 Base-T Ethernet
management port in the form xxx.xxx.xxx.xxx where:
xxx.xxx.xxx.xxx=IP Address
COMMAND EXAMPLE: <0001/IPG=010.006.030.001{CR}
2 bytes Query only.
Returns Interface Type in the form s, where:
s=Interface Slot 1 or 2
QUERY EXAMPLE: <0001/ITF?1{CR}
>0001/ITF=1x{CR}{LF} where x=active interface type:
0=CDI-40 ASI (Interface Slot 1 only)
1=CDI-70 GBEI (Interface Slot 2 only)
2=CDI-60 HSSI (Interface Slot 1 only)
9–19
Description of Arguments
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
IEP= N/A
IEP?
IEP*
IEP#
IMG= IMG=n
IMG?
IMG*
IMG#
IMP= IMP=x
IMP?
IMP*
IMP#
IPA= IPA=xxx.xxx.xxx.
IPA? xxx.yy
IPA*
IPA#
IPG= IPG=xxx.xxx.xxx.
IPG? xxx
IPG*
IPG#
ITF? ITF=sx
ITF*
ITF#
