CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
Rx Clock RCI= RCI?s
Inverted
Rx Clock RCK= RCK?s
Source
Rx Data RDI= RDI?s
Invert
Rx Data Rate N/A RDR?
Redundancy RED= RED?
State
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
2 bytes Command or Query.
Sets or returns CDI-60 HSSI Inverted Rx Clock in the form sx where:
s=1 (Interface Slot 1 only)
x=CDI-60 HSSI Inverted Rx Clock where 0=Normal, 1=Inverted
NOTE: Not valid for Slot 1 CDI-40 ASI or Slot 2 CDI-70 GBEI operation.
2 bytes Command or Query.
Sets or returns CDI-60 HSSI Rx Clock Source (for data rate accuracy) in the
form sx, where:
s=1 (Interface Slot 1 only)
x=Rx Clock Source where 0=Rx Satellite, 1=Tx-Terrestrial, 2=External
Reference Clock, 3=Internal
NOTE: Not valid for Slot 1 CDI-40 ASI or Slot 2 CDI-70 GBEI operation.
COMMAND EXAMPLE: <0001/RCK=11{CR} (sets Tx-Terrestrial)
2 bytes Command or Query.
Sets or returns the CDI-60 HSSI Invert Rx Data in the form sx where:
s=1 (Interface Slot 1 only)
x=Invert Rx Data where 0=Normal, 1=Inverted
NOTE: Not valid for Slot 1 CDI-40 ASI or Slot 2 CDI-70 GBEI operation.
10 bytes Query only.
Returns the Composite Rx Data rate, in the form xxxxxx.xxx where:
xxxxxx.xxx=rate in kbps, in 1 bps steps.
EXAMPLE: <0001/RDR?{CR}
>0000/RDR=002047.999 (reports 2047.999 kbps data rate)
1 byte Command or Query.
Sets or returns the redundancy state of the unit in the form x where:
0=Offline
1=Online
NOTES:
1) The unit cannot be forced online. You can force the unit offline by
sending RED=0.This is only valid if redundancy mode is enabled. If
redundancy is not enabled, then RED=0 will return an error.
2) The unit is always online if Redundancy Mode is not selected.
9–64
Description of Arguments
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
RCI = RCI=sx
RCI?
RCI *
RCI #
RCK= RCK=sx
RCK?
RCK*
RCK#
RDI = RDI=sx
RDI?
RDI*
RDI#
RDR? RDR=xxxxxx.xxx
RDR*
RDR#
RED= RED=x
RED?
RED*
RED#
