CDM-710/L Broadcast Satellite Modem
Front Panel Operation
This read-only status message indicates the Data Rate of the Tx (transmit)
MPEG-2 transport stream. Press ENTER or CLEAR to return to the previous
menu.
(Config:) Intfc1 HSSI:  Tx  Data  Invert
Use this feature to ensure compatibility with certain older equipment. Use the 
 arrow keys to select Normal or Inverted. Press ENTER.
(Config:) Intfc1 HSSI:  Tx  Clock
Use this feature to ensure compatibility with certain older equipment. Use the
arrow keys to select Normal or Inverted. Press ENTER.

(Config:) Intfc1 HSSI:  Tx  Enable
Use the   arrow keys to select Enable to activate the Tx side of this interface,
or Disable to de-activate the Tx side and set the Data Rate to 0. Press ENTER.
(Config:) Intfc1 HSSI:  Rx
Use the   arrow keys to select Data, Buffer, Clock, or Enable. Press ENTER.
Intfc1 Tx Data Invert:
Normal Inverted
Intfc1 Tx Clock:
Normal Inverted
Intfc1 Tx Enable:
Enable Disable
Intfc1 Rx:
Data Buffer Clock
7–34
MN/CDM710.IOM
(E)
(E)
(E)
Enable
Revision 12

