CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
GBEI Stream GTM= GTM?
Timeout
Mode
GBEI Stream GTO= GTO?
Timeout
Initialize IEP= N/A
Events
Pointer
Boot Image IMG= IMG?
Management IPA= IPA?
IP Address
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
2 bytes Command or Query.
Sets or returns the CDI-70 GBEI Stream Timeout Mode in the form sm, where:
s=2 (Interface Slot 2 only)
m=Mode where 0=Non-revertive, 1=Revertive
NOTE: Used in Dual Stream Mode ONLY. When in redundancy mode, this
parameter controls whether the GBEI switches back and forth between the
two input streams for a valid MPEG stream. Revertive (GSM=1) means the
interface will switch back and forth between the two streams. Non-revertive
(GSM=0) is a latching scheme where the interface will only switch to the
secondary stream.
3 bytes Command or Query.
Sets or returns the CDI-70 GBEI Stream Timeout in the form stt, where:
s=2 (Interface Slot 2 only)
t=Timeout, from 0 to 10, in 100 mS steps
NOTE: Used in Dual Stream Mode ONLY.
None Command only.
THIS COMMAND TAKES NO ARGUMENTS.
Resets the internal pointer to allow RNE? queries to start at the beginning of
the stored events log.
EXAMPLE: <0001/IEP={CR} (resets stored events log internal pointer)
1 byte Command only.
Selects the Boot image in the form n where:
n=FW Image 1 or 2
COMMAND EXAMPLE: <0001/IMG=1{CR} (sets Image 1 for bootup)
18 bytes Command or Query.
Sets or returns the IP Address and Subnet Mask for the 10/100 BaseT 'J4 |
Ethernet' management port in the form xxx.xxx.xxx.xxx.yy where:
xxx.xxx.xxx.xxx=IP Address
yy=Subnet Mask (00 to 31)
COMMAND EXAMPLE: <0001/IPA=010.006.030.001.24{CR}
9–61
Description of Arguments
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
GTM= GTM=sm
GTM#
GTM?
GTM*
GTO= GTO=stt
GTO#
GTO?
GTO*
IEP= N/A
IEP?
IEP*
IEP#
IMG= IMG=n
IMG?
IMG*
IMG#
IPA= IPA=xxx.xxx.xxx.
IPA? xxx.yy
IPA*
IPA#
