CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
Firmware N/A FRW?i
Revisions
GBEI FEC GFE= GFE?
Enable
GBEI FEC GFP= GFP?
Base Port
GBEI GIP= GIP?s
Management
IP Address
and Subnet
GBEI GMI= GMI?
Multicast IP
Address
GBEI Active GSA= GSA?
Stream
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
1 byte Query only.
Returns the firmware information of the system where:
i=Bulk Image number (1 or 2)
a=Firmware Image
b=Firmware Revision
c=Firmware Date
EXAMPLE: <0001/FRW?1{CR}
2 bytes Command or Query.
Sets or returns the CDI-70 GBEI FEC mode in the form sn, where:
s=2 (Interface Slot 2 only)
n=Disable/Enable where 0=Disabled, 1=Enabled
6 bytes Command or Query.
Sets or returns the CDI-70 GBEI FEC Base Port number in the form snnnnn,
where:
s=2 (Interface Slot 2 only)
n=Port Number (0 to 65535)
19 bytes Command or Query.
Sets or returns the CDI-70 GBEI Management IP Address and Subnet Mask in
the form sxxx.xxx.xxx.xxx.yy where:
s=2 (Interface Slot 2 only)
xxx.xxx.xxx.xxx=IP Address
yy=Subnet Mask
COMMAND EXAMPLE: <0001/GIP=2192.168.001.001.24{CR}
17 bytes Command or Query.
Sets or returns the CDI-70 GBEI Multicast Address in the form
smxxx.xxx.xxx.xxx, where:
s=2 (Interface Slot 2 only)
m=Multicast Stream (1 or 2)
xxx.xxx.xxx.xxx=IP Address
2 bytes Command or Query.
Sets or returns the CDI-70 GBEI Active Stream in the form sm, where:
s=2 (Interface Slot 2 only)
m=Active Multicast Stream (1 or 2)
9–17
Description of Arguments
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
FRW? FRW={CR}Boot:{
FRW* CR}a,b,c{CR}Bul
FRW# ki:{CR}a,b,c{CR}
a,b,c...
GFE= GFE=sn
GFE#
GFE?
GFE*
GFP= GFP=snnnnn
GFP#
GFP?
GFP*
GIP= GIP=sxxx.xxx.xxx
GIP# .xxx.yy
GIP?
GIP*
GMI= GMI=smxxx.xxx.
GMI# xxx.xxx
GMI?
GMI*
GSA= GSA=sm
GSA#
GSA?
GSA*
