CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
GBEI Egress GEG= GEG?
Multicast
Group
Address
GBEI Egress GEP= GEP?s
Port Numbers
GBEI Egress GFM= GFM?s
FEC Matrix
GBEI GIP= GIP?s
Management
IP Address
and Subnet
Initialize IEP= N/A
Events
Pointer
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
16 bytes Command or Query.
Sets or returns the CDI-70 GBEI Egress Multicast Group Address. The
multicast stream egressing from the CDI-70 GBEI will have this source IP
address in the form sxxx.xxx.xxx.xxx, where:
s=2 (Interface Slot 2 only)
xxx.xxx.xxx.xxx=IP Address
11 bytes Command or Query.
Sets or returns the CDI-70 GBEI Egress Port Numbers in the form
snnnnnppppp, where:
s=2 (Interface Slot 2 only)
nnnnn = Source Port Number, value in the range from 0 to 65535
ppppp = Destination Port Number, vale in the range from 0 to 65535
NOTE: Both Source Port and Destination Port must be valid for set command
to take effect.
11 bytes Command or Query.
Sets or returns the CDIU-70 GBEI Egress FEC Matrix in the form sll,dd where:
s=2 (Interface Slot 2 only)
ll = Length, two digit number (leading zero) from 1 to 20.
dd = Depth, two digit number (leading zero) from 4 to 20.
NOTE: Length x Depth, must be (less than or equal to) ≤100
19 bytes Command or Query.
Sets or returns the CDI-70 GBEI Management IP Address and Subnet Mask in
the form sxxx.xxx.xxx.xxx.yy where:
s=2 (Interface Slot 2 only)
xxx.xxx.xxx.xxx=IP Address
yy=Subnet Mask
COMMAND EXAMPLE: <0001/GIP=2192.168.001.001.24{CR}
None Command only.
THIS COMMAND TAKES NO ARGUMENTS.
Resets the internal pointer to allow RNE? queries to start at the beginning of
the stored events log.
EXAMPLE: <0001/IEP={CR} (resets stored events log internal pointer)
9–35
Description of Arguments
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
GEG= GEG=sxxx.xxx.xx
GEG# x.xxx
GEG?
GEG*
GEP= GEP=snnnnnppp
GEP# pp
GEP?
GEP*
GFM= GFM=sll,dd
GFM #
GFM?
GFM*
GIP= GIP=sxxx.xxx.xxx
GIP# .xxx.yy
GIP?
GIP*
IEP= N/A
IEP?
IEP*
IEP#
