CDM-710/L Broadcast Satellite Modem
Front Panel Operation
(UTIL:) Firmware:  Info  Image#X  Interfaces  ASI
Press ENTER or CLEAR to return to the previous menu.
(UTIL:) Firmware:  Info  Image#X  Interfaces  GBEI
(INTERFACE SLOT 2 ONLY)
The firmware for the CDI-70 10/100/1000 Base-T Gigabit Ethernet Data
Interface (GBEI) is installed on the GBEI module itself; information is
returned only when a CDI-70 module is installed in Interface Slot 2.
Press ENTER or CLEAR to return to the previous menu.
(UTIL:) Firmware:  Select
The top line displays the active image. Use the
line to select #1 or #2 as the active software image. Press ENTER.
You must power cycle / reboot the modem to make the selected image the
active choice.
ASI:
FW12546D
GBEI: 6/26/07
FW12738A 1.1.9
Current Active Image: #2
Next Reboot Image: #1 #2
7–72
MN/CDM710.IOM
07/25/07
2.2.1
arrow keys on the bottom
 
Revision 12
