Page 1 CDM-710 Broadcast Satellite Modem Installation and Operation Manual IMPORTANT NOTE: The information contained in this document supersedes all previously published information regarding this product. Product specifications are subject to change without prior notice. MN/CDM710.IOM Revision 9...
Page 3 Revision 9 December 4, 2007 Comtech EF Data is an ISO 9001 Registered Company Copyright © Comtech EF Data, 2007. All rights reserved. Printed in the USA. Comtech EF Data, 2114 West 7th Street, Tempe, Arizona 85281 USA, 480.333.2200, FAX: 480.333.2161...
Page 4 This page is intentionally blank.
Page 5: Table Of Contents
Table of Contents PREFACE ..........................XI Customer Support ............................xi About this Manual ............................ xii Reporting Comments or Suggestions Concerning this Manual .............. xii Conventions and References ........................xii Metric Conversion ..........................xii Cautions and Warnings ........................... xii Recommended Standard Designations ....................xiii Electrical Safety ............................
Page 6 CDM-710 Broadcast Satellite Modem Revision 9 Table of Contents MN/CDM710.IOM Mounting ............................2–1 2.2.1 Optional Rear-Mounting Support Brackets ................2–2 CHAPTER 3. FUNCTIONAL AND PHYSICAL DESCRIPTIONS .......... 3–1 Front Panel ..........................3–2 Dimensional Envelope ........................ 3–3 CHAPTER 4. CONNECTOR PINOUTS ................. 4–1 External Connections ........................
Page 7 CDM-710 Broadcast Satellite Modem Revision 9 Table of Contents MN/CDM710.IOM Config: Tx: Code Rate ........................ 5–13 Config: Tx: SymRate ........................5–13 Config: Tx: Mode ........................5–17 Config: Tx: Frequency ........................ 5–17 Config: Tx: Pwr .......................... 5–17 Config: Tx: Pwr: Level ....................... 5–18 Config: Tx: Pwr: On/Off ......................
Page 8 CDM-710 Broadcast Satellite Modem Revision 9 Table of Contents MN/CDM710.IOM Config: Intfc1: HSSI: Rx: Invert ....................5–37 Config: Intfc1: HSSI: Rx: Buffer ....................5–37 Config: Intfc1: HSSI: Rx: Buffer: Size ..................5–37 Config: Intfc1: HSSI: Rx: Buffer: ReCenter ................5–37 Config: Intfc1: HSSI: Rx: Clock ....................
Page 9 CDM-710 Broadcast Satellite Modem Revision 9 Table of Contents MN/CDM710.IOM CHAPTER 6. FLASH UPGRADING ..................6–1 Ethernet FTP upload procedure: ....................6–2 CHAPTER 7. FORWARD ERROR CORRECTION OPTIONS ..........7–1 Introduction ..........................7–1 Viterbi and Reed Solomon ......................7–1 LDPC and BCH ........................... 7–2 7.3.1...
Page 10 CDM-710 Broadcast Satellite Modem Revision 9 Table of Contents MN/CDM710.IOM 9.5.3 Remote Ethernet Group ......................9–4 9.5.4 Ethernet SNMP Group ......................9–4 9.5.5 Interface FEC Group ......................9–4 9.5.6 Modem Reference Group ...................... 9–4 9.5.7 Monitor Group ........................9–4 9.5.8 Test Group ..........................
Page 11 CDM-710 Broadcast Satellite Modem Revision 9 Table of Contents MN/CDM710.IOM 12.1 Introduction ..........................12–1 12.2 Physical Description ........................12–3 12.3 General Specifications ......................12–3 12.4 Connector Pinout ........................12–5 CHAPTER 13. WEB SERVER PAGES ................13–1 13.1 Web Server Usage ........................13–1 13.1.1...
Page 12 Table 8-5. Eb/No Performance for DSNG 16-QAM Operations .............. 8–9 Table 11-1. Interface Specifications ......................11–2 Table 11-2. Connector Pinout ......................... 11–5 Table 12-1. Interface Specifications ....................... 12–3 Table 12-2. Connector Pinout ........................ 12–5 Table 13-1. CDM-710 Web Server Menu Tree ..................13–2...
Page 13 Table of Contents MN/CDM710.IOM Figures Figure 1-1. CDM-710 Broadcast Satellite Modem (Shown with Different Keypads) ....... 1–1 Figure 1-2. Block Diagram ........................1–2 Figure 2-1. Installation of the Optional Rear-Mounting Support Brackets ..........2–3 Figure 3-1. Front Panel ..........................3–2 Figure 3-2.
Page 14 CDM-710 Broadcast Satellite Modem Revision 9 Table of Contents MN/CDM710.IOM This page is intentionally left blank.
Page 15: Preface
480.333.2200 (Main Comtech EF Data number) 480.333.4357 (Customer Support Desk) 480.333.2161 FAX To return a Comtech EF Data product (in-warranty and out-of-warranty) for repair or replacement: Contact the Comtech EF Data Customer Support Department. Be prepared to supply the Customer Support representative with the model number, serial number, and a description of the problem.
Page 16: About This Manual
For information regarding this product‟s warranty policy, refer to the Warranty Policy, p. xvi. About this Manual This manual provides installation and operation information for the Comtech EF Data CDM-710 Broadcast Satellite Modem. This is a technical document intended for earth station engineers, technicians, and operators responsible for the operation and maintenance of the CDM-710.
Page 17: Recommended Standard Designations
IMPORTANT Fuses The CDM-710 is fitted with two fuses - one each for line and neutral connections. These are contained within the body of the IEC power inlet connector, behind a small plastic flap. For 115 and 230 volt AC operation, use T2.00A, 20mm fuses.
Page 18: Environmental
The equipment is not designed for connection to power system that has no direct connection to ground. The CDM-710 is shipped with a line inlet cable suitable for use in the country of operation. If it is necessary to replace this cable, ensure the replacement has an equivalent specification. Examples of acceptable ratings for the cable include HAR, BASEC and HOXXX-X.
Page 19: Rohs Compliancy
CDM-710 Broadcast Satellite Modem Revision 9 Preface MN/CDM710.IOM RoHS Compliancy This unit satisfies (with exemptions) the requirements specified in the European Union Directive on the Restriction of Hazardous Substances, Directive 2002/95/EC, (EU RoHS). EMC (Electromagnetic Compatibility) In accordance with European Directive 89/336/EEC, the CDM-570/570L Modem has been...
Page 20: Warranty Policy
During the warranty period, Comtech EF Data will, at its option, repair or replace products that prove to be defective. For equipment under warranty, the owner is responsible for freight to Comtech EF Data and all related customs, taxes, tariffs, insurance, etc.
Page 21: Exclusive Remedies
Preface MN/CDM710.IOM A fixed charge established for each product will be imposed for all equipment returned for warranty repair where Comtech EF Data Corporation cannot identify the cause of the reported failure. Exclusive Remedies Comtech EF Data Corporation‟s warranty, as stated is in lieu of all other warranties, expressed, implied, or statutory, including those of merchantability and fitness for a particular purpose.
Page 22 CDM-710 Broadcast Satellite Modem Revision 9 Preface MN/CDM710.IOM Notes: xviii...
Page 23: Chapter 1. Introduction
Chapter 1. INTRODUCTION The CDM-710 Broadcast Satellite Modem (Figure 1-1) is a high symbol/bit-rate unit, intended for operation in broadcast and enterprise applications. It operates over satellite links at symbol/data rates up to 45 Msps. Various modulations and coding combinations compliant with DVB-S, DVB-DSNG and DVB-S2 are provided.
Page 24: Standard And Optional Features
CDM-710 Broadcast Satellite Modem Revision 9 Introduction MN/CDM710.IOM The modem is compact, being 1RU high x 18.65 inches deep with low power consumption. It has a front panel VFD display and keypad for local configuration and control, although it can be fully remote-controlled via a RS-485 bus or 10/100 Base-T Ethernet Interface.
Page 25: Software - Flash Upgrading
CDM-710 Broadcast Satellite Modem Revision 9 Introduction MN/CDM710.IOM 1.1.1 Software – Flash Upgrading The internal software is both powerful and flexible, permitting storage and retrieval of up to 10 different configurations. The modem uses ‘flash memory’ technology internally, and new firmware is uploaded to the unit from an external PC.
Page 26: Redundancy Support
CDM-710 Broadcast Satellite Modem Revision 9 Introduction MN/CDM710.IOM Redundancy Support Redundancy support for the CDM-710 is as follows (refer also to para. 1.1.3): • 1:1 Redundancy(CDI-40 ASI only): CRS-170A (L-Band) or CRS-180 (70/140 MHz) • CRS-170A MN/CRS170A.IOM • CRS-180 MN/CRS180.IOM Major Assemblies Later units are Rev A chassis and later.
Page 27: Chapter 2. Installation
Chapter 2. INSTALLATION Unpacking Inspect shipping containers for damage. If shipping containers are damaged, keep them until the contents of the shipment have been carefully inspected and checked for normal operation. The modem and manual are packaged in pre-formed, reusable, cardboard cartons containing foam spacing for maximum shipping protection.
Page 28: Optional Rear-Mounting Support Brackets
CDM-710 Broadcast Satellite Modem Revision 9 Installation MN/CDM710.IOM 2.2.1 Optional Rear-Mounting Support Brackets Install optional rear-mounting support brackets using mounting kit KT/6228-2: Quantity Part Number Description HW/10-32SHLDR Screw, #10 Shoulder HW/10-32FLT Washer, #10 Flat HW/10-32SPLIT Washer, #10 Split HW/10-32HEXNUT Nut, #10 Hex...
Page 29: Figure 2-1. Installation Of The Optional Rear-Mounting Support Brackets
CDM-710 Broadcast Satellite Modem Revision 9 Installation MN/CDM710.IOM Equipment Rack Rear Mounting Rail #10 Shoulder Screw Support Bracket #10 Flat Washer #10 Flat Washer #10 Bracket Bolt #10 Split Washer #10 Hex Nut Back of unit Figure 2-1. Installation of the Optional Rear-Mounting Support Brackets...
Page 30 CDM-710 Broadcast Satellite Modem Revision 9 Installation MN/CDM710.IOM Notes: 2–4...
Page 31: Chapter 3. Functional And Physical Descriptions
Chapter 3. FUNCTIONAL AND PHYSICAL DESCRIPTIONS The modem is constructed as a 1RU high rack-mounting chassis, which can be freestanding, if desired. Rack handles at the front facilitate removal from and placement into a rack. The satellite modem performs several key functions: It accepts incoming data from the terrestrial interface and converts it into appropriate clock and data signals.
Page 32: Front Panel
CDM-710 Broadcast Satellite Modem Revision 9 Functional and Physical Description MN/CDM710.IOM An Rx carrier from the satellite is received by the demodulator and reverses the process performed by the modulator. The demodulator has an FEC decoder that corrects errors incurred during transmission to improve the integrity of the data delivered to the data interface.
Page 33: Dimensional Envelope
CDM-710 Broadcast Satellite Modem Revision 9 Functional and Physical Description MN/CDM710.IOM Dimensional Envelope All dimensions are in English units (centimeters are in parentheses). 18.65 1.72 (473.7) (43.7) 19.00 16.98 (482.6) (431.3) 1.71 (43.4) Figure 3-2. Dimensional Envelope 3–3...
Page 34 CDM-710 Broadcast Satellite Modem Revision 9 Functional and Physical Description MN/CDM710.IOM Notes: 3–4...
Page 35: Chapter 4. Connector Pinouts
Chapter 4. CONNECTOR PINOUTS External Connections External cables are attached to connectors on the rear panel. The connector configurations differ between chassis type and revision (70/140 MHz vs. L-Band, and initially released chassis vs. Rev. A and later), as shown in Figure 4-1. Slot 1 Slot 2 Initially released chassis (70/140 MHz shown...
Page 36: Table 4-1. Modem Rear Panel Connectors For Initially Released Chassis
CDM-710 Broadcast Satellite Modem Revision 9 Connector Pinouts MN/CDM710.IOM Table 4-1. Modem Rear Panel Connectors For Initially Released Chassis Name Ref Des Connector Type Function Tx/IF Output BNC, female IF Output 70/140 MHz Type N, female L-Band Output Rx/IF Input...
Page 37: 10/100 Ethernet Remote Port Connector Pinout, J4
CDM-710 Broadcast Satellite Modem Revision 9 Connector Pinouts MN/CDM710.IOM 4.1.2 10/100 Ethernet Remote Port Connector Pinout, J4 The Remote connector is a RJ-45 female type. Pin # Description Direction 4.1.3 SerDes Port Connector, J6 (Initially Released Chassis Only) RJ-45: Private communications link – not available for customer use.
Page 38: External Reference Input (Main Chassis), J7
CDM-710 Broadcast Satellite Modem Revision 9 Connector Pinouts MN/CDM710.IOM 4.1.5 External Reference Input (Main Chassis), J7 The Ext Ref (External Reference) input is used to supply a master reference to the entire chassis. The clocks on the Framer Card and the Modulator and Demodulator Synthesizers are locked to...
Page 39: Rs-232/-485 Remote Port Connector Pinout, P2
CDM-710 Broadcast Satellite Modem Revision 9 Connector Pinouts MN/CDM710.IOM Redundancy is available only with the Rev. A chassis or later. 1:N (CRS-300/700) And 1:1 Mode (CRS-170A, CRS-180) Pin # Description Name Direction Summary Relay NC (De-energized, Faulted) PR-NC, * Summary Relay NO (Energized, No Fault)
Page 40 CDM-710 Broadcast Satellite Modem Revision 9 Connector Pinouts MN/CDM710.IOM Notes: 4–6...
Page 41: Chapter 5. Front Panel Operation
Description Figure 5-1. Front Panel View The user can fully control and monitor the operation of the CDM-710 from the front panel, using the keypad and display. Nested menus display all available options, and prompt the user to carry out a required action.
Page 42: Led Indicators
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.1.1 LED Indicators The behavior of the front panel LEDs is described below in Table 5-1. Table 5-1. Front Panel LED Indicators Color Condition Green No Unit Faults or Alarms exists...
Page 43: Keypad
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.1.2 Keypad The keypad is shown in Figure 5-2: Diamond Keypad: Earlier Chassis Button Keypad: Rev. A or Later Chassis Figure 5-2. Keypad The function of these keys is as follows: ENTER This key is used to select a displayed function or to execute a modem configuration change.
Page 44: Menu Tree
2. Refer to Config:Tx: SymRate for the Data Rate table. 3. The Impedance selection appears when the 70/140 MHz Modulator card is installed. 4. The Scrambler selection appears if the Mode selection is DVB-S2. Figure 5-3. CDM-710 Menu Tree 5–4...
Page 45: Opening Screen
Firmware Version: X.X.X The bottom line displays the internal software version. Press ENTER to go to the Main Menu screen. The unit being tested could be CDM-710 or CDM-710L. For purposes of this documentation a CDM-710 was used. IMPORTANT Main Menu...
Page 46: Config
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.3.1 CONFIG CONFIG: Remote Tx Rx Int1 Int2 Ref Aux Alarms The sub-branches available are: Remote Permits the user to define whether the unit is being controlled locally, or (Remote Control) remotely.
Page 47: Config: Remote Control
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.3.1.1 Config: Remote Control Remote Control: Local Serial Ethernet Select Local, Serial or Ethernet by using the  arrow keys, then press ENTER Local If Local is selected the remote control is disabled. Remote monitoring is still possible.
Page 48: Config: Remote Control: Serial: Baudrate
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM RS485 is selected, the user will be further prompted: RS485 Mod Address: 0001 (E) Edit the RS485 address of the modem. This is accomplished by selecting the digit to be edited, using the arrow keys.
Page 49: Config: Remote Control: Ethernet: Gateway
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Remote Control: Ethernet: Gateway Gateway is selected: Ethernet IP Gateway: 063.168.001.127 ( E ) Use the  arrow keys to edit the Gateway address and press ENTER to accept the value.
Page 50: Config: Tx
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Community is selected: SNMP Community: Read ( E ) Read Community: ( E ) public 5.3.1.2 Config: Tx Tx:FEC Mod Code SymRate Mode Freq Pwr Scram(E) The Scram(bler) selection only appears if the Mode selection is DVB- IMPORTANT This modem is configured with the Mode as the highest priority.
Page 51: Config: Tx: Tx Modulation
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Tx: Tx Modulation If the Tx Modulation is selected: Tx Modulation: Type Inv  Pilot Frame (E) The Pilot and Frame selections only appear if the Mode selection is DVB- IMPORTANT ...
Page 52: Config: Tx: Tx Modulation
The selections Avg/Peak sets the pilots and header to the average power band of the transmitted constellation(QPSK, 8PSK, 16APSK or 32APSK) per DVB-S2 and to the outer ring of the transmitted constellation(QPSK, 8PSK, 16APSK or 32ASK) respectively. The CDM-710 automatically adjusts but the default value is Avg.
Page 53: Config: Tx: Tx Modulation: Frame Size
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Tx: Tx Modulation: Frame Size This menu is only available when the Mode selection is DVB-S2. IMPORTANT Tx Frame Size: Long Short (E) This menu is active only in the DVB-S2 mode. The selection Long enables the standard FECFRAME = 64,800 bits and selecting Short enables the 16,200 bit frame.
Page 54 CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM When modulation, code rate and other parameters are changed the modem attempts to maintain the same symbol rate, provided it is still in range when one of the other parameters is changed.
Page 55 CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Symbol Rate / Data Rate Range – Standard FEC Frame and 188 Byte Format Symbol Rate Data Rate (Mbps) Data Rate (Mbps) Spectral Spectral Inner (Msps) Pilot OFF Pilot ON...
Page 56 CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Symbol Rate / Data Rate Range – Short FEC Frame and 188 Byte Format Symbol Rate Data Rate (Mbps) Data Rate (Mbps) Inner Spectral Spectral (Msps) Pilot OFF Pilot ON...
Page 57: Config: Tx: Mode
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Tx: Mode Transmission Mode: DVB-S2 DVB-S DVB-DSNG The Mode is a key parameter for setting all modem parameters, and it is generally easier if it is set first. The Mode determines which modulation, code rates, FEC type and symbol rate range are available and also if Pilots or Gold Code settings are available.
Page 58: Config: Tx: Pwr: Level
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Tx: Pwr: Level TX Output Power Level: -10.0 dBm ( E) Edit the TX Power level. This is accomplished by selecting the digit to be edited, using the ...
Page 59: Config: Tx: Scram
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Tx: Scram The Scam(bler) menu is available only when the Mode selection is DVB-S2. IMPORTANT Tx Scrambling Index: Gold-n = 000000 (E) The Scrambling menu is active only for DVB-S2. Use the arrow keys to select the desired digit.
Page 60: Config: Rx: Demod
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Rx: Demod If the Dem is selected: Rx Demod: Type Inv Acq  Eq IQ-TP Pilot Scr (E) The Pilot and Scrambler selections only appear if the Mode selection is DVB-S2.
Page 61: Config: Rx: Dem: Acq
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Rx: Dem: Acq is selected: Demod Acquisition Range: +/-010 kHz (E) Edit the acquisition search range of the demodulator (the value entered here determines the amount of frequency uncertainly the demodulator will search over in order to find and lock to an incoming carrier).
Page 62: Config: Rx: Dem: Iq-Tp
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Rx: Dem: IQ-TP If IQ-TP is selected: Rx IQ TPs (J2-11,J2-3): Pre-EQ Post-EQ (E) This selection determines whether the IQ test point located on the Alarm Connector samples the IQ signal before or after the Adaptive Equalizer.
Page 63: Config: Rx: Code Rate
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Rx: Code Rate If Code Rate is selected: Code Rate: 1/2 3/5 2/3 3/4 4/5 5/6 7/8 8/9 9/10 The cursor only lands on valid code rates depending upon the mode and purchased options. If the Mode is set to DVB-S2 the menu is read only and the demodulator automatically resolves the code rate.
Page 64: Config: Rx: Mode
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Demod Unlocked In DVB-S2 mode appears while the Rx path is not synchronized. After synchronization the correct data rate appears in the display and the demodulator has automatically resolved the modulation type, code rate, pilots ON/OFF, FECframe length, spectral inversion, etc.
Page 65: Config: Rx: Eb/No
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Rx: Eb/No Eb/No is selected: Eb/No Alarm: Threshold Alarm/Fault (E) Threshold Alarm/Fault Masked Select , or using the arrow keys. The user should then press ENTER Config: Rx: Eb/No: Threshold...
Page 66: Config: Intfc2 (For Gigabit Ethernet Interface Only)
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.3.1.4 Config: Intfc2 (For Gigabit Ethernet Interface Only) Note: Assumes the interface is installed in Slot 1. For this discussion;  Ingress refers to IP packets received from the LAN ...
Page 67: Config: Intfc2: Ingress: Fec
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Intfc2: Ingress: FEC is selected: Intfc2 Ingress FEC Enable Disable Enable Disable Select Enable Select for the GbEI to perform SMPTE 2022 / Pro-MPEG COP3 error recovery. Select Disable to bypass the SMPTE 2022 / Pro-MPEG COP3 function.
Page 68: Config: Intfc2: Streams: Mode
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Group is selected: Enter Source Multicast IP address for stream 2. is selected: Intfc2 Address 2 Group Source Group Source Select Group is selected: Intfc2 Multicast 2: 224.001.001.001  Enter Group Multicast IP address for stream 2.
Page 69: Config: Intfc2: Streams: Primary
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Intfc2: Streams: Primary Primary is selected: Intfc2 Primary Stream Select either stream 1 or stream 2 as the primary stream. In single mode, this assigns which (of up to two) streams is processed. In redundancy mode, this identifies which of two streams are initially processed before any redundancy switch takes place.
Page 70 CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Ena/Dis is selected: Intfc2 Egress Enable: Enable Disable Enable Enter to enable reception of the MPEG transport stream from the WAN. Entering enable also enables transmission of the IP-encapsulated MPEG packets to the LAN (egress).
Page 71: Config: Intfc1: Man
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Group is selected: Intfc2 Egress Multicast: 239.010.010.010  Enter the valid destination IP multicast group address for egress IP packets. Src Port is selected: Intfc2 Egress Src Port: 01024 ...
Page 72 CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM GBEI Statistics Summary LAN Good Octets (In) – The sum of lengths of all good Ethernet frames received 1000Base-T Link Statistics from the LAN LAN Bad Octets (In) – The sum of lengths of all bad Ethernet frames received from the LAN LAN Unicast (In) –...
Page 73 CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM GBEI Statistics Summary FPGA Media Unrecovered – When FEC is enabled, indicates number of bad or lost Ethernet packets that could not be recovered, for which a packet with a payload of null MPEG packets has been substituted FPGA UDP Checksum Error –...
Page 74: Config: Intfc1 (Cdi-60 Hssi)
Mng Multicast (Out) – The sum of frames transmitted to the local GBEI management processor that have a multicast destination MAC address 5.3.1.5 Config: Intfc1 (CDI-60 HSSI) The menus are shown for the HSSI Interface installed in Slot1. The CDM-710 supports a single HSSI Interface (Intfc1). Intfc1 HSSI: Tx Rx CTS/RTS (E)
Page 75: Config: Intfc1: Hssi: Tx: Data
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Intfc1: HSSI: Tx: Data Intfc1 Tx Data: Datarate Invert (E)  Select Datarate or Invert, using the arrow keys. The user should then press [ENTER]. Config: Intfc1: HSSI: Tx: Datarate...
Page 76: Config: Intfc1: Hssi: Tx: Enable
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Intfc1: HSSI: Tx: Enable Intfc1 Tx Enable: Enable Disable (E)  Select Enable or Disable, using the arrow keys. The user should then press [ENTER]. This selection is use to activate and deactivate the Tx side of this interface.
Page 77: Config: Intfc1: Hssi: Rx: Invert
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Intfc1: HSSI: Rx: Invert Intfc1 Rx Data Invert: Normal Inverted (E)  Select Normal or Inverted, using the arrow keys to control data inversion (added for compatibility with certain older equipment).
Page 78: Config: Intfc1: Hssi: Rx: Clock
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Intfc1: HSSI: Rx: Clock Intfc1 Rx Clock: Source Invert (E)  Select Source or Invert using the arrow keys. The user should then press [ENTER]. Config: Intfc1: HSSI: Rx: Clock: Source...
Page 79: Config: Intfc1: Hssi: Tx: Rts/Cts
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Config: Intfc1: HSSI: Tx: RTS/CTS Intfc1 CTS/RTS: Normal Fault  Select Normal or Fault using the arrow keys. The user should then press [ENTER]. RTS is the same as TA and CTS is the same as CA. The selections operate as follows: Normal: CTS = RTS Fault: CTS = RTS when no fault is present.
Page 80 CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Intfc1 ASI Rx: Enable Disable ( E) Selecting Enable or Disable activates or deactivates the Rx side of this interface. Disabling the Rx side deactivates it and sets the data rate to 0.
Page 81: Config: Ref
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.3.1.7 Config: Ref Frequency Reference External 10 MHz (E) The unit phase locks to an external input at the BNC External 10 MHz connector labeled EXT REF. Other selections are available for External 1, 2, 5, 10, or 20 MHz input.
Page 82: Alarm: Tx
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.3.1.10 Alarm: Tx is selected: Tx Alarm Mask: None Currently, masking of Tx Alarms (associated with the modulator) is not allowed. Config: Alarm: Intfc2 Note: This message is only valid for the ASI Interface.
Page 83: Monitor: Alarms: Live Alarms: Rx
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Monitor: Alarms: Live Alarms: Rx RX Traffic: Demod Unlocked This will report only if Demod is unlocked, otherwise it will report “No Errors.” Monitor: Alarms: Live Alarms: Unit Unit Fault: No Errors The menu screen appears on the left and a brief description appears on the right.
Page 84: Monitor: Event-Log
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM For DVB-S and DVB-DSNG only: EsNo=16.0 PER=N/A  EbNo=15.1 BER=0.0E+00  EbNo=15.1 BER=0.0E+00 F=-000.1k  RSL=-16 F=-000.4k  RSL=-16 Link_Margin=+10.1 Note: In this mode, BER monitoring is not available. Link Margin corresponds to:...
Page 85: Monitor: Event-Log: Stored Events: View
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Monitor: Event-Log: Stored Events: View Log015 23/05/06 09:27:15 Fault – No PHY Link ()  This window displays (253) Alarms.    To display the alarms press keys to display the individual alarm.
Page 86: Table 5-2. Summary Of Alarms Reported For Tx And Unit Categories
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Table 5-2. Summary of Alarms Reported for Tx and Unit Categories Unit Faults / Alarms Menu Mnemonic Description FPGA Load Framer Card Framer FPGA not loading +1.5V JPSU Framer Card 1.5V Vdc Framer / FEC regulator exceeds +/- 5%...
Page 87 CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Demodulator Faults / Alarms Menu Mnemonic Description Encoder FIFO Empty Transmit Encoder FIFO is empty Encoder FIFO Full Transmit Encoder FIFO is full ASI TrxSlot 1 DR > +110PPM Transmit data rate exceeds nominal by >+100PPM Slot 1 ASI TrxSlot 2 DR >...
Page 88: Test
Test selections for the Tx carrier and Patterns are selected in this menu. Test: Mode The CDM-710 supports many useful test modes. Not all modes are available in all configurations. They depend upon the modem configuration (Duplex, Rx-Only, Tx-Only) and the data interface(s).
Page 89: Test: Test Patterns
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Test: Test Patterns Test Pattern Subst: Off 2047 2^23-1 (E) Traffic Data Flow - Block Diagram The availability of test patterns depends on the type of interface. Framer Card Interface Card...
Page 90 CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Figure 5-4. Traffic Data Flow – Loopback Block Diagrams (Continued) 5–50...
Page 91: Info
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.3.4 INFO INFO: Rem Tx Rx Intfc1 Intfc2 (E) This menu sequentially displays all Info screens on a read-only basis: the user is not permitted to edit an Info screen, just view it.
Page 92: Info: Rx
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM INFO: Rx RX: 0140.0000 17.379483 DVBS2 QP 1/2 LF The info items are as follows: 0140.0000 Tx Frequency in MHz 17.279483 Data rate in Mbps DVBS2 Transmission mode: DVBS2 DVB-S...
Page 93: Save/Load
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.3.5 Save/Load Save/Load Configuration: Save Load (E) Save Load  Select , using arrow keys, then press ENTER These sub-menus permit the user to store or load up to 10 different modem configurations in a non-volatile memory of the modem.
Page 94: Utility
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.3.6 Utility UTIL: RT-Clk Ref ID Display Firmware FAST 5.3.6.1 Utility: RT-Clk Edit Real-Time Clock: 10:23:51 23/05/06 ( E) Edit the time and date settings of the real-time clock. This is accomplished by selecting the digit to be changed, using the ...
Page 95: Utility: Id
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.3.6.3 Utility: ID Edit Circuit ID: ( E) ------------------------ Edit the Circuit ID string, using the  arrow keys. Only the bottom line is available (24 characters). The cursor selects the position on the bottom line () and the character is then edited ().
Page 96: Utility: Firmware: Info: Image
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Utility: Firmware: Info: Image Image#1: Bulk App Framer FEC Mod Demod Interfaces Note: The following information is representative. Actual status is viewed in the modem menu. Utility: Firmware: Info: Image#1...
Page 97: Utility: Firmware: Select
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM Utility: Firmware: Info: Image#2: XXXXXX Bulk Bulk: 10/16/06 FW12437- 2.1.1 App: 10/16/06 FW12438 2.1.1 Framer Framer: 08/09/06 FW12548- 2.1.1 Enc-S2 Enc-S Dec-S2 FEC: Enc-S2 DVB-S2 Enc 09/14/06 FW12439- 1.0.1 FEC: Enc-S...
Page 98: Utility: Fast
CDM-710 Broadcast Satellite Modem Revision 9 Front Panel Operation MN/CDM710.IOM 5.3.6.6 Utility: FAST: FAST:Cnfg View MainBoard S/N: 333333333 Utility: FAST: Configuration If Cnfg is selected: FAST Configuration Edit Code Demo Mode Utility: FAST: Configuration: Edit Edit is selected: Edit 20 digit FAST Code:...
Page 99: Chapter 6. Flash Upgrading
IMPORTANT The CDM-710 eliminates the need for updating firmware by physically replacing EPROMs. Instead, the CDM-710 modem uses „flash memory‟ technology internally, and new firmware can be uploaded to the unit from an external PC, as follows: Go online to: www.comtechefdata.com...
Page 100: Ethernet Ftp Upload Procedure
CDM-710 Broadcast Satellite Modem Revision 9 Flash Upgrading MN/CDM710.IOM Ethernet FTP upload procedure: 1. Identify the reflashable product, firmware number, and version for download. The current base modem M&C version can be viewed at the top-level menu of the front panel display (press “CLR”...
Page 101 Note: FW12050x.txt for earlier units. c. README.TXT installation notes 5. Connect the client PC to the CDM-710 modem 10/100 Ethernet M&C via a hub or a switch, or directly to a PC with a crossover cable. Verify the communication and connection by issuing a "ping" command to the modem.
Page 102 CDM-710 Broadcast Satellite Modem Revision 9 Flash Upgrading MN/CDM710.IOM 8. Verify the file transfer. a. The PC should report that the file transfer has occurred, and the display on the modem will start reporting “PROGRAMMING FLASH SECTOR#xx – PLEASE WAIT”.
Page 103: Introduction
Chapter 7. FORWARD ERROR CORRECTION OPTIONS Introduction The CDM-710 Modem operates with error correction base upon the DVB standards: DVB-S: QPSK with concatenated Viterbi and Reed Solomon. DVB-DSNG: 8-PSK and 16-QAM with concatenated Viterbi and Reed Solomon. DVB-S2: QPSK, 8-PSK, 16-APSK and 32-APSK with concatenated Low Density Parity Code (LDPC) and Bose-Chaudhuri-Hocquenghem (BCH).
Page 104: Ldpc And Bch
CDM-710 Broadcast Satellite Modem Revision 9 Forward Error Correction Options MN/CDM710.IOM LDPC and BCH LDPC and BCH is also concatenated technique. LDPC is a very powerful coding scheme with significant, near Shannon bound, performance. In some cases, as the carrier to noise ratio increases, the LDPC error correction starts flaring toward an error floor so BCH error correction follows LDPC and eliminates the flare for any practical range of error rates.
Page 105: Table 7-1. Eb/No, Spectral Efficiency And Occupied Bandwidth
Symbol Rate, for 35% Rolloff = 1.15 Symbol Rate, for 25% Rolloff = 1.12 x Symbol Rate, for 20% Rolloff Table 7-1 provides the Eb/No, spectral efficiency and occupied bandwidth for the CDM-710. Table 7-1. Eb/No, Spectral Efficiency and Occupied Bandwidth Occupied * Inner...
Page 106 CDM-710 Broadcast Satellite Modem Revision 9 Forward Error Correction Options MN/CDM710.IOM QPSK 1/4, 1/3 and 2/5 are for information purposes. DVB-S2 Standard FECFrame = 64, 800 bits Inner **Es/No Spectral Normalized * Occupied Spectral Normalized * Occupied At PER =...
Page 107 CDM-710 Broadcast Satellite Modem Revision 9 Forward Error Correction Options MN/CDM710.IOM QPSK 1/4, 1/3 and 2/5 are for information purposes. Es/No for short FECFrame is about 0.3 dB higher than the standard. Values in the table are approximate. DVB-S2 Short FECFrame = 16,200 bits...
Page 108: Figure 7-1. Dvb-S Qpsk Ber Versus Eb/No
CDM-710 Broadcast Satellite Modem Revision 9 Forward Error Correction Options MN/CDM710.IOM 1.0E-05 DVB-S: QPSK BER vs Eb/No 1.0E-06 1.0E-07 1.0E-08 1.0E-09 1.0E-10 Eb/No (dB) Figure 7-1. DVB-S QPSK BER versus Eb/No 7–6...
Page 109: Figure 7-2. Dvb-Dsng 8-Psk Ber Versus Eb/No
CDM-710 Broadcast Satellite Modem Revision 9 Forward Error Correction Options MN/CDM710.IOM 1.0E-03 DVB-DSNG: 8-PSK BER vs Eb/No 1.0E-04 1.0E-05 1.0E-06 1.0E-07 1.0E-08 1.0E-09 1.0E-10 1.0E-11 Eb/No (dB) Figure 7-2. DVB-DSNG 8-PSK BER versus Eb/No 7–7...
Page 110: Figure 7-3. Dvb-Dsng 16-Qam
CDM-710 Broadcast Satellite Modem Revision 9 Forward Error Correction Options MN/CDM710.IOM 1.0E-03 DVB-DSNG: 16-QAM BER vs Eb/No 1.0E-04 1.0E-05 1.0E-06 1.0E-07 1.0E-08 1.0E-09 1.0E-10 1.0E-11 Eb/No (dB) Figure 7-3. DVB-DSNG 16-QAM 7–8...
Page 111: Figure 7-4. Dvb-S2 Qpsk Packet Error Rate Versus Es/No (Qpsk 1/4, 1/3, And 2/5, Information Only)
CDM-710 Broadcast Satellite Modem Revision 9 Forward Error Correction Options MN/CDM710.IOM 1.0E-02 DVB-S2: QPSK PER vs Es/No 1.0E-03 9/10 1.0E-04 1.0E-05 1.0E-06 1.0E-07 Es/No (dB) Figure 7-4. DVB-S2 QPSK Packet Error Rate versus Es/No (QPSK 1/4, 1/3, and 2/5, Information Only)
Page 112: Figure 7-5. Dvb-S2 8-Psk Packet Error Rate Versus Es/No
CDM-710 Broadcast Satellite Modem Revision 9 Forward Error Correction Options MN/CDM710.IOM 1.0E-02 DVB-S2: 8-PSK PER vs Es/No 1.0E-03 9/10 1.0E-04 1.0E-05 1.0E-06 1.0E-07 Es/No (dB) Figure 7-5. DVB-S2 8-PSK Packet Error Rate versus Es/No 7–10...
Page 113: Figure 7-6. Dvb-S2 16-Apsk Packet Error Rate Versus Es/No
CDM-710 Broadcast Satellite Modem Revision 9 Forward Error Correction Options MN/CDM710.IOM 1.0E-02 DVB-S2: 16-APSK PER vs Es/No 1.0E-03 9/10 1.0E-04 1.0E-05 1.0E-06 1.0E-07 Es/No (dB) Figure 7-6. DVB-S2 16-APSK Packet Error Rate versus Es/No 7–11...
Page 114: Figure 7-7. Dvb-S2 32-Apsk Packet Error Rate Versus Es/No
CDM-710 Broadcast Satellite Modem Revision 9 Forward Error Correction Options MN/CDM710.IOM 1.0E-02 DVB-S2: 32-APSK PER vs Es/No 1.0E-03 9/10 1.0E-04 1.0E-05 1.0E-06 1.0E-07 Es/No (dB) Figure 7-7. DVB-S2 32-APSK Packet Error Rate versus Es/No 7–12...
Page 115: Chapter 8. Summary Of Specifications
20%, 25%, or 35% (per DVB-S, DSNG, S2) See Figure 8-1 and Table 8-1. M&C/Remote Port RS-232 and RS-485 2W/4W with Comtech EF Data protocol 10/100 Base-T Ethernet with HTTP, SNMP or Telnet Physical (PL) Layer User specified value (one) of n = 0 to 262,141, per EN 302 307.
Page 116: Environmental And Physical
CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM Description Requirements 1:1 Redundancy Built in controller for operation with optional CRS-170A for L-Band and CRS-180 for 70/140 MHz Fault Form C, see connector pinout information and notes Configuration Non-volatile for 1-year minimum and returns upon power up.
Page 117: 70/140 Mhz Modulator
CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM 70/140 MHz Modulator Description Requirements Frequency 52 to 88 MHz or 104 to 176 MHz in 100Hz steps. Bandwidth of transmitted spectrum is within IF frequency range. Impedance or 50 , programmable...
Page 118: L-Band Modulator
CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM L-Band Modulator Description Requirements Frequency 950 to 1950 MHz in 100Hz steps. Bandwidth of transmitted spectrum is within IF frequency range. Impedance Connector Type N Male Return Loss 15 dB Output Power -5 to -25 dBm in 0.1 dB steps.
Page 119: Table 8-1. Definition Of Points For Spectral Mask
CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM R e la tiv e pow e r (dB) f/ f Figure 8-1. Spectral Mask Table 8-1. Definition of Points For Spectral Mask Frequency Frequency Frequency Relative power Point Group delay...
Page 120: 70/140 Mhz Demodulator
CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM 70/140 MHz Demodulator Description Requirements Frequency Range 52 to 88 and 104 to 176 MHz in 100 Hz steps Impedance/Connector or optional 75 /BNC Female Return Loss 15 dB Input Power, Minimum -58 + 10xLog(Symbol Rate in MHz) dBm, -58 dBm at 1 Msps, -41.5 dBm at 45 Msps.
Page 121: Figure 8-2. Demodulator Input Level
CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM Carrier Input Level (vs) Symbol Rate Maximum Level Minimum Level Symbol Rate (Msps) Figure 8-2. Demodulator Input Level 8–7...
Page 122: Table 8-2. Eb/No Performance At Quasi Error Free Per = 10
CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM Table 8-2. Eb/No Performance at Quasi Error Free PER = 10 with AWGN for DVB-S2 Operations FECFRAME = 64,800 or 16,200 Bits and no pilot Spectral Spectral Specified Modulation Code...
Page 123: Test Functions
CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM Table 8-3. Eb/No Performance for DVB-S QPSK Operations Eb/No (dB) Table 8-4. Eb/No Performance for DSNG 8-PSK Operations Eb/No (dB) Table 8-5. Eb/No Performance for DSNG 16-QAM Operations Eb/No (dB) 10.0...
Page 124: Remote Port Operation
CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM Remote Port Operation Description Requirements Comtech EF Data See remote port chapter. Remote Port Ethernet Telnet Ethernet transport of standard Remote Control commands. Ethernet SNMP See SNMP Chapter Ethernet HTTP Support all control and monitor parameters.
Page 125 CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM 188 Byte Format Symbol Rate Spectral Data Rate (Mbps) Spectral Data Rate (Mbps) Inner (Msps) Pilot OFF Pilot ON Efficiency Efficiency Modulation FEC Code Code Rate Pilot OFF Pilot ON DVB-S2 - Standard FEC Frame = 64,800 Bits 0.490243 0.490243 22.060942 0.478577 0.478577 21.535965...
Page 126 CDM-710 Broadcast Satellite Modem Revision 9 Summary of Specifications MN/CDM710.IOM 188 Byte Format Symbol Rate Data Rate (Mbps) Data Rate (Mbps) Inner Spectral Spectral (Msps) Pilot OFF Pilot ON Modulation FEC Code Code Efficiency Efficiency Rate Pilot OFF Pilot ON DVB-S2 - Short FEC Frame = 16,200 Bits 0.365324 0.365324 16.439560 0.357467 0.357467 16.086022...
Page 127: Chapter 9. Snmp Interface
The CDM-710 SNMP agent supports both SNMPv1 and v2c. For proper SNMP operation, the CDM-710 MIB files must be used with the associated version of the CDM-710 modem M&C Software. Refer to the CDM-710 SW Release Notes for information on the required FW/SW compatibility.
Page 128 These MIB files should be compiled in a MIB Browser or SNMP Network Monitoring System server. Note: The CDM-710 SNMP agent supports both SNMPv1 and v2c. The CDM-710 Traps file only needs to be compiled if SNMPv1 traps are to be used.
Page 129: Snmp Community Strings
The CDM-710 has the ability to send out SNMP traps when certain events occur in the modem. For example, the CDM-710 also sends out traps when an alarm or a fault occurs in the modem. These include unit faults, TX faults, and RX faults. A trap is sent both when a fault occurs and is cleared.
Page 130: Remote Ethernet Group
CDM-710 Broadcast Satellite Modem Revision 9 SNMP Interface MN/CDM710.IOM 9.5.3 Remote Ethernet Group This group provides the parameters of the modem’s Ethernet interface. This includes the IP Address and Mask, IP Gateway, and MAC Address. 9.5.4 Ethernet SNMP Group This group provides the parameters necessary to configure and operate the SNMP interface. This includes the System Name, Administrator and Location as well as the Community Strings.
Page 131: Firmware Group
OID information please refer to the actual MIB file. ASI Private MIB The CDM-710 ASI MIB holds all unit parameters associated with the ASI interface board. For detailed OID information please refer to the actual MIB file. Redundancy-Switch Private MIB The CDM-710 Modem MIB holds all unit parameters associated with 1:1 Redundancy operations.
Page 132 CDM-710 Broadcast Satellite Modem Revision 9 SNMP Interface MN/CDM710.IOM Notes: 9–6...
Page 133: Chapter 10. Cdi-40 Asi Data Interface
Chapter 10. CDI-40 ASI Data Interface 10.1 Introduction This data interface is a plug-in module that inserts into the rear of the modem chassis. It provides physical and electrical connection between the external terrestrial device and the internal circuitry of the modulator or demodulator. By convention, a modem is Data Communications Equipment (DCE) where transmit data enters the data interface and receive data exits it.
Page 134: Figure 10-1. Asi Interface Block Diagram
CDM-710 Broadcast Satellite Modem Revision 9 CDI-40 ASI Data Interface MN/CDM710.IOM Processor Dejittered ASI Data & ASI Input Dejitter Dejitter Tx-1 Data FIFO FIFO Mux/ Receiver Recovered ASI Clk Receiver & PLL & PLL Demux ASI Input Modem Tx-2 A/B Select...
Page 135: Figure 10-4. Asi Interface Diagram (Later Pl/10881-4)
CDM-710 Broadcast Satellite Modem Revision 9 CDI-40 ASI Data Interface MN/CDM710.IOM Dejittered ASI Data ASI Input Tx-1 Dejitter & Dejitter Processor Recovered ASI Clk Processor FIFO Data FIFO Receiver Receiver & PLL & PLL ASI Input Mux / Mux /...
Page 136: General Specifications
CDM-710 Broadcast Satellite Modem Revision 9 CDI-40 ASI Data Interface MN/CDM710.IOM 10.2 General Specifications The interface operates to the specifications described in Table 10-1. Table 10-1. Interface Specifications General Specifications Data Framing Formats ASI: 188 or 204 byte packets per ETS 300 421.
Page 137: Input/Output Data Formats
CDM-710 Broadcast Satellite Modem Revision 9 CDI-40 ASI Data Interface MN/CDM710.IOM PCR Jitter (RX Output) Less than 100ns after settling Settling to < 500ns, 20 seconds Peak PCR jitter < 1000ns typical during settling 10.3 Input/Output Data Formats The ASI interface operates at a 270 Mbps transport rate for all data rates. The required encoding of this transport is defined in EN 80053-9 and the Cypress Hotlink IC data sheets.
Page 138: Connector Pinouts
CDM-710 Broadcast Satellite Modem Revision 9 CDI-40 ASI Data Interface MN/CDM710.IOM 0x47 0x1F, 0xFF, 0x1F 0xFF Not Specified Sync Bytes 2-5 Byte 10.4 Connector Pinouts 10.4.1 ASI Connector Pinout The ASI interface is as follows: PL/10881-3 Connector Description Signal Direction...
Page 139: Chapter 11. Cdi-70 1000 Base-T (Gbe) Interface
Chapter 11. CDI-70 1000 Base-T (GbE) INTERFACE 11.1 Introduction The CDI-70 Gigabit Base-T Ethernet Interface or GbE performs a Motion Picture Expert Group (MPEG-2) packet decapsulation operation on ingress Internet Protocol (IP) packets received from the Local Area Network (LAN). MPEG-2 packets are extracted from the active (of up to two multicast) connection and forwards the extracted MPEG-2 packets to Wide Area Network (WAN) (satellite connection).
Page 140: Physical Description
The GbE is implemented on a 3.95 x 7.022 inch (10.03 x 17.83 cm) PCB. Connectivity to the CDM-710 will be implemented with a 96-pin DIN receptacle, and the LAN interface consists of an RJ-45 connector with link status and link activity Light-Emitting Diode (LED).
Page 141 CDM-710 Broadcast Satellite Modem Revision 9 1000 Base-T (GbE) Interface MN/CDM710.IOM Monitor & Control 1000Base-T Link Ingress good octets Statistics Ingress bad octets Ingress unicast packets Ingress broadcast packets Ingress multicast packets Ingress pause packets Ingress undersize packets Ingress fragments...
Page 142 CDM-710 Broadcast Satellite Modem Revision 9 1000 Base-T (GbE) Interface MN/CDM710.IOM Monitor & Control (Continued) Management Port Ingress good octets Statistics Ingress bad octets Ingress unicast packets Ingress broadcast packets Ingress multicast packets Ingress pause packets Ingress undersize packets Ingress fragments...
Page 143: Connector Pinout
CDM-710 Broadcast Satellite Modem Revision 9 1000 Base-T (GbE) Interface MN/CDM710.IOM Management Management Packet Packet Processor Processor & Data Ethernet RJ-45 Layer 2 Packet RJ-45 Layer 2 Packet Modem Interface Switch Processor Switch Processor Interface Memory Memory Gigabit Ethernet Card Figure 11-2.
Page 144: Gbei Software Upload Procedure
CDM-710 Broadcast Satellite Modem Revision 9 1000 Base-T (GbE) Interface MN/CDM710.IOM 11.5 GBEI Software Upload Procedure The GBEI interface board contains its own processor and memory. On occasion, CEFD may release new software to fix anomalies or add functionality to this interface board. This section will define how to perform this upgrade process.
Page 145 CDM-710 Broadcast Satellite Modem Revision 9 1000 Base-T (GbE) Interface MN/CDM710.IOM The current version firmware release is provided. If applicable, one version prior to the current release is also available. Be sure to identify and download the desired version. The downloadable files are stored in two formats: *.exe (self extracting) and *.zip (compressed).
Page 146 CDM-710 Broadcast Satellite Modem Revision 9 1000 Base-T (GbE) Interface MN/CDM710.IOM 7. Transfer the files. Type "put FW12547*.bin bulk:" to begin the file transfers. The destination “bulk:” must be all lower-case. It will take approximately ten minutes to transfer the file – wait for this transfer to take place before proceeding to the next step.
Page 147: 1000 Base-T Ethernet (Gbe) Interface Card Removal And Installation
CDM-710 Broadcast Satellite Modem Revision 9 1000 Base-T (GbE) Interface MN/CDM710.IOM 11.6 CDI-70 1000 Base-T Ethernet (GbE) Interface Card Removal and Installation Ensure the unit is in a Power Off mode. Serious injury or damage to the equipment could result.
Page 148 CDM-710 Broadcast Satellite Modem Revision 9 1000 Base-T (GbE) Interface MN/CDM710.IOM Notes: 11–10...
Page 149: Introduction
Chapter 12. CDI-60 HSSI Interface 12.1 Introduction This data interface is a plug-in module that inserts into the rear of the modem chassis. It provides physical and electrical connection between the external terrestrial device and the internal circuitry of the modulator or demodulator. By convention, a modem is Data Communications Equipment (DCE) where Tx data enters the data interface and Rx data exits it.
Page 150: Figure 12-1. Hssi Interface Block Diagram
CDM-710 Broadcast Satellite Modem Revision 9 CDI-60 HSSI Interface MN/CDM710.IOM Figure 12-2 shows a picture of the CDI-60 HSSI interface and the SCSI-2 connector that serves as the data port. A summary of specifications for the interface is provided in Table 12-1 and the connector pinout is shown in Table 12-2.
Page 151: Physical Description
CDM-710 Broadcast Satellite Modem Revision 9 CDI-60 HSSI Interface MN/CDM710.IOM 12.2 Physical Description The HSSI Interface is implemented on a 3.95 x 7.022 inch (10.03 x 17.83 cm) PCB. Connection to the modem is provided when the 96-pin DIN connector is engaged into the modem slot. The HSSI interface consists of a 50-pin SCSI connector and an activity Light-Emitting Diode (LED) that is lit when the interface is enabled.
Page 152: Figure 12-3. Continuous And Gap Clock At Tt
CDM-710 Broadcast Satellite Modem Revision 9 CDI-60 HSSI Interface MN/CDM710.IOM Item Requirement Test I/O Loopback not provided Operation Simplex (Tx only or Rx only) or full duplex Signal Sense Programmable Normal or Inverted for TT and TD, RT and RD Cards Per Modem The interface operates in Slot 1.
Page 153: Connector Pinout
CDM-710 Broadcast Satellite Modem Revision 9 CDI-60 HSSI Interface MN/CDM710.IOM 12.4 Connector Pinout The HSSI interface has a 50 pin female SCSI-2 connector (mini-D) with the pinout shown in Table 12-2. Table 12-2. Connector Pinout HSSI/EIA-613 Interface Connector Pinout Signal Function...
Page 154 CDM-710 Broadcast Satellite Modem Revision 9 CDI-60 HSSI Interface MN/CDM710.IOM Notes: 12–6...
Page 155: Chapter 13. Web Server
The embedded Web Server application provides the user with an easy to use interface to configure and monitor all aspects of the CDM-710 Modem. The web page is available via the management Ethernet port of the CDM-710, J4, only. These web pages have been designed for optimal performance when using Microsoft’s Internet Explorer 5.5 or higher.
Page 156: Web Server Menu Tree
CDM-710 Broadcast Satellite Modem Revision 9 Web Server Pages MN/CDM710.IOM 13.1.1 Web Server Menu Tree Table 13-1. CDM-710 Web Server Menu Tree Level 1 Level 2 Home Home Contact Support Access Admin Remote Config Mdm Interface Modem Modem Utilities Stats Modem Status Events &...
Page 157: Login Prompt
CDM-710 Broadcast Satellite Modem Revision 9 Web Server Pages MN/CDM710.IOM 13.2.2 Login Prompt By typing http://xxx.xxx.xxx.xxx” (where xxx.xxx.xxx.xxx = modem IP address) on your browser, the Login prompt will appear: Figure 13-1. Web Interface – Login Window Note: Only one remote method can be in control of either Ethernet or Serial while the other can be used for query.
Page 158: Home
CDM-710 Broadcast Satellite Modem Revision 9 Web Server Pages MN/CDM710.IOM 13.3 Home Pages 13.3.1 Home Page Figure 13-2. Web Interface – Home Page Modem Welcome to the CDM-710 Web Interface. The following sections will describe the functionality that is unique to the Web Interface.
Page 159: Contact Information
CDM-710 Broadcast Satellite Modem Revision 9 Web Server Pages MN/CDM710.IOM 13.3.2 Contact Information Figure 13-3. Web Interface – Contact page This page provides basic contact information to reach Comtech EF Data Sales and Customer Support via phone or automated e-mail links. 13–5...
Page 160: Support
13.3.3 Support Figure 13-4. Web Interface – Customer Support page Notes on SMTP – SMTP can be used to send an email to Comtech EF Data Modem Support cdmipsupport@comtechefdata.com from the Support Web Page. The Support Web Page allows Modem you to compose an email message for questions or problems with the .
Page 161: Smtp Configuration Page
@ symbol in an email address). SMTP Destination Name Set the email recipient names (usually found to the left of the @ symbol in an email address). SMTP can be used to send an email to Comtech EF Data Modem Support cdmipsupport@comtechefdata.com using the Support NOTE Web Page by connecting to the modem with a Web Browser.
Page 162 CDM-710 Broadcast Satellite Modem Revision 9 Web Server Pages MN/CDM710.IOM Notes: 13–8...
Page 163: Appendix A. Remote Control
Introduction This section describes the protocol and message command set for remote monitor and control of the CDM-710 Satellite Modulator. The electrical interface is either an RS-485 multi-drop bus (for the control of many devices) or an RS-232 connection (for the control of a single device), and data is transmitted in asynchronous serial form, using ASCII characters.
Page 164: Basic Protocol
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Each target has a unique address, and each time the controller transmits, in a framed ‘packet’ of data, the address of the intended recipient target is included. All of the targets receive the packet, but only one (the intended) will reply.
Page 165: Packet Structure
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Packet Structure Controller-to-target: Start of Packet Target Address Address Instruction Code Optional End of Packet De-limiter Code Qualifier Arguments < = or ? Carriage Return ASCII code 60 ASCII code 47 ASCII code 61...
Page 166: Instruction Code
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM A.5.3 Instruction Code This is a three-character alphabetic sequence which identifies the subject of the message. Wherever possible, the instruction codes have been chosen to have some significance. For example TFQ for transmit frequency, etc. This aids in the readability of the message, should it be displayed in its raw ASCII form.
Page 167: Message Arguments
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM First, if the controller has sent a query code to a target (for example TFQ?, meaning ‘what’s the Transmit frequency?’), the target would respond with TFQ=xxxx.xxxx, where xxxx.xxxx represents the frequency in question.
Page 168 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Remote Specification Table of Contents Address ............................A–2, A–3 AEQ ............................A–32, A–60 Alarm ................A–16, A–24, A–32, , A–44, A–60, A–61, A–73 A–34 ARF ............................. A–36, A–63 ATF ............................. A–17, A–63 Basic Protocol ............................
Page 169 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Instruction Code Qualifier ........................A–4 IPA ........................... A–23, A–43, A–72 IPG ........................... A–23, A–43, A–72 ITF ........................... A–23, A–43, A–72 LNK ............................A–36, A–63 LRS ..........................A–23, A–44, A–72 MAC ..........................A–23, A–44, A–72 Message Arguments ..........................
Page 170 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM TIP .............................. A–14, A–53 TLP ............................. A–13, A–52 TMD .............................. A–9, A–48 TMM ............................. A–9, A–48 TMP ..........................A–26, A–47, A–75 TPI .............................. A–13, A–52 TPL ............................. A–11, A–50 TPT ............................. A–26, A–75 TRC ............................
Page 171 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Modulator Priority System = TMM (Highest priority), TMD, TCR, and TSR (Lowest Priority). Any change to a higher priority parameter can override any of the parameters of lower priority. Command Arguments Query...
Page 172 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx FEC Code TCR= 1 byte...
Page 173 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx Power Level TPL= 5 bytes...
Page 174 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx FEC Type 1 byte...
Page 175 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx Frame Size TFS= 1 byte...
Page 176 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx ASI TAB= 2 bytes...
Page 177 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx Clock TCI= 2 bytes Command or Query.
Page 178 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Transmit & TRC= 69 bytes...
Page 179: Configuration
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) ASI Tx Frame ATF= 2 bytes...
Page 180 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Equipment ID 23 bytes Unit returns equipment identification and configuration,...
Page 181 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) External ERF= 1 byte External Reference Frequency, where:...
Page 182 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) b = Tx Traffic Status: 0=No faults 1= +1.5V Power Supply Unit (Modulator Card)
Page 183 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Firmware 1 byte Query the version information of the system. Where:...
Page 184 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Gigabit Primary GSP= 2 bytes...
Page 185 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) IP Address IPA= 18 bytes...
Page 186 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Unit Alarm MSK= 2 bytes...
Page 187 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Retrieve next 5 75 bytes...
Page 188 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Demodulator Priority System = RMM (Highest priority), RMD, RCR, and RSR (Lowest Priority). Any change to a higher priority parameter can override any of the parameters of lower priority. Command Arguments Query...
Page 189 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx FEC Code RCR= 1 byte...
Page 190: Dlk
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx Frequency 5 bytes Query only.
Page 191 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx FEC Type 1 byte...
Page 192 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx Frame Size 1 byte...
Page 193: Eba
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx Clock RCI= 2 bytes Command or Query.
Page 194 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) RBS= 5 bytes Command or Query. Rx Buffer Size (in milliseconds), where:...
Page 195 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Transmit & TRC= 69 bytes...
Page 196 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx Eb/No 4 bytes Query only.
Page 197 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx Link 4 bytes Query only.
Page 198 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Real-time DAY= 6 bytes A date in the form ddmmyy, where...
Page 199: Eid
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Equipment ID 23 bytes Unit returns equipment identification and configuration,...
Page 200: Erf
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) External ERF= 1 byte External Reference Frequency, where:...
Page 201 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) b = Tx Traffic Status: 0=No faults A–40...
Page 202 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) c=Rx Traffic Status 0=No faults 1=+1.5V Demod Power Supply Unit (Demodulator Card)
Page 203: Gef
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Firmware 1 byte Query the version information of the system. Where:...
Page 204 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Gigabit GIP= 19 bytes Gigabit Management IP address and subnet mask.
Page 205 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Local/Remote LRS= 1 byte Local/Remote status, where:...
Page 206 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Redundancy RED= 1 byte, value...
Page 207 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Retrieve next 5 75 bytes...
Page 208 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Real-time TIM= 6 bytes A time in the form hhmmss, indicating the time from midnight,...
Page 209 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Modem Priority System = TMM (Highest priority), TMD, TCR, and TSR (Lowest Priority). Any change to a higher priority parameter can override any of the parameters of lower priority. Command Arguments Query...
Page 210 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx FEC Code TCR= 1 byte...
Page 211 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx Power Level TPL= 5 bytes...
Page 212 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx FEC Type 1 byte...
Page 213 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx Frame Size TFS= 1 byte...
Page 214 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx ASI TAB= 2 bytes...
Page 215 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Tx Clock TCI= 2 bytes Command or Query.
Page 216 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Priority System = RMM (Highest priority), RMD, RCR, and RSR (Lowest Priority). Any change to a higher priority parameter can override any of the parameters of lower priority. Command Arguments Query Response...
Page 217 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx FEC Code RCR= 1 byte...
Page 218 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx Frequency 5 bytes Query only.
Page 219 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx FEC Type 1 byte...
Page 220 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx Frame Size 1 byte...
Page 221 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Enable/Disable AEQ= 1 byte Adaptive Equalizer status, where:...
Page 222 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Transmit & TRC= 69 bytes...
Page 223 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx Eb/No 4 bytes Query only.
Page 224 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Rx Link 4 bytes Query only.
Page 225 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Configuration CLD= 1 byte Retrieves a previously stored configuration from the specified...
Page 226 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Equipment ID 23 bytes Unit returns equipment identification and configuration,...
Page 227 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) External ERF= 1 byte External Reference Frequency, where:...
Page 228 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) b = Tx Traffic Status: 0=No faults 1= +1.5V Power Supply Unit (Modulator Card)
Page 229 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) C=Rx Traffic Status 0=No faults 1=+1.5 Demod Power Supply Unit (Demodulator Card)
Page 230: Gfp
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) D=New Faults 0=No new faults...
Page 231: Gsi
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Gigabit Source GSI= 17 bytes...
Page 232: Iep
CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Gigabit Egress GEF= 2 bytes Gigabit Egress FEC Enable/Disable.
Page 233 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) IP Address IPA= 18 bytes...
Page 234 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Unit Alarm MSK= 2 bytes...
Page 235 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Retrieve next 5 75 bytes...
Page 236 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Command Arguments Query Response Parameter (Instruction for Command (Instruction Description of Arguments Response to Query Type Code and or Response Code and Command Qualifier) to Query Qualifier) Real-time TIM= 6 bytes A time in the form hhmmss, indicating the time from midnight,...
Page 237 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM Modem Global Configuration (MGC) Command The MGC command can be used to configure the whole modem or parts of the modem. This command also contains spare bytes for future development, but the length of the command is fixed to 255 bytes. The MGC command can be used on modulator-only units, demodulator-only units, and modem units.
Page 238 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM [Tx Block] consists of 50 bytes for Transmit configuration, the format is: aaaa.aaaabcc.ccccccdefghhh.hijklmmmmmmxxxxxxxxxxxx aaaa.aaaa = Tx Frequency (in MHz) same as TFQ b = Tx Mode same as TMM cc.cccccc = Tx Symbol Rate...
Page 239 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM [Interface Block] consists of 130 bytes and contains the configuration of the current enabled interface on the unit. The format of the configuration bytes depend on the interface type indicated by the 5 byte in the MGC query or command.
Page 240 CDM-710 Satellite Modulator Revision 9 Remote Control MN/CDM710.IOM If HSSI interface, then format is: a = Tx Data Inversion same as TDI (omit interface slot parameter) b = Rx Data Inversion same as RDI (omit interface slot parameter) c = Tx Clock Inversion...
Page 241 Appendix B. Eb/No MEASUREMENT Although the CDM-710 calculates and displays the value of receive Eb/No on the front panel of the unit, it is sometimes useful to measure the value using a spectrum analyzer, if one is available. B–1...
Page 242 CDM-710 Broadcast Satellite Modem Revision 9 Eb/No Measurement MN/CDM710.IOM The idea is to accurately measure the value of (Co+No)/No, (Carrier density + Noise density/Noise density). This is accomplished by tuning the center frequency of the Spectrum analyzer to the signal of interest, and measuring the difference between the peak spectral density of the signal (the flat part of the spectrum shown) and the noise density.
Page 243 CDM-710 Broadcast Satellite Modem Revision 9 Eb/No Measurement MN/CDM710.IOM CDM-710 Co+No/No to C/N (Es/No) and Eb/No (dB) For DVB-S And DVB-DSNG Code Rate QPSK 8PSK 16QAM Spectral Efficiency 0.921569 1.228758 1.382353 1.535948 1.612745 1.843137 2.303922 2.457516 2.764706 3.225490 (Co+No)/No C/N = Es/No...
Page 244 CDM-710 Broadcast Satellite Modem Revision 9 Eb/No Measurement MN/CDM710.IOM CDM-710 Co+No/No to C/N (Es/No) and Eb/No (dB) For DVB-S2 QPSK and 8-APSK (DVB-S2 uses C/N (Es/No), and Eb/No is shown for information) Code Rate QPSK 8PSK Spectral Efficiency 0.490243 0.656448 0.789412...
Page 245 CDM-710 Broadcast Satellite Modem Revision 9 Eb/No Measurement MN/CDM710.IOM CDM-710 Co+No/No to C/N (Es/No) and Eb/No (dB) For DVB-S2 16-APSK and 32-APSK (DVB-S2 uses C/N (Es/No), and Eb/No is shown for information) Code Rate 16APSK 32APSK Spectral Efficiency 2.637201 2.966728 3.165623...
Page 246 CDM-710 Broadcast Satellite Modem Revision 9 Eb/No Measurement MN/CDM710.IOM This page is intentionally blank. B–6...
Page 247 METRIC CONVERSIONS Units of Length Unit Centimeter Inch Foot Yard Mile Meter Kilometer Millimeter 1 centimeter — 0.3937 0.03281 0.01094 6.214 x 10 0.01 — — 1 inch 2.540 — 0.08333 0.2778 1.578 x 10 0.254 — 25.4 1 foot 30.480 12.0 —...
Page 248 2114 85281 WEST TH STREET TEMPE ARIZONA 480 • 333 • 2200 PHONE 480 • 333 • 2161...

Comtech EF Data CDM-710 Installation And Operation Manual

Quick Links

Chapters

Related Manuals for Comtech EF Data CDM-710

Summary of Contents for Comtech EF Data CDM-710
