CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
Transmit & TRC= TRC?
Receive
Configuration
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
69 bytes Command or Query.
Sets or returns the current transmit and receive configuration in the form
aaa.aaaabcc.ccccccdefghhhhhhiii.ijkllll.llllmnn.nnnnnnopqrsssssstuvv, where:
aaaa.aaaa=Tx Frequency (in MHz) (same as TFQ)
b=Tx Mode (same as TMM)
cc.cccccc=Tx Symbol Rate (same as TSR)
d=Tx FEC Type (same as TFT **)
e=Tx Modulation type (same as TMD)
f=Tx FEC Rate (same as TCR)
g=Tx Spectrum Inversion (same as TSI)
hhhhhh=Tx Gold Code Sequence (same as TGS)
iii.i=Tx Power Level (same as TPL)
j=Tx Carrier State (same as TXO)
k=Tx Alpha Roll-off (same as TAR)
llll.llll=Rx Frequency (in MHz) (same as RFQ)
m=Rx Mode (same as RMM)
nn.nnnnnn=Rx Symbol Rate (same as RSR)
o=Rx FEC Type (same as RFT **)
p=Rx Modulation type (same as RMD)
q=Rx FEC Rate (same as RCR)
x=spare
ssssss=Rx Gold Code Sequence (same as RGS)
t=Rx Alpha Roll-off (same as RAR)
u=Unit test Mode (same as TST**)
vv=Unit Alarm Mask (same as MSK)
NOTES:
1) ** indicates Read-only.
2) Unit returns 'x's for Rx parameters if unit is Modulator Only.
3) Unit returns 'x's for Tx parameters if unit is Demodulator Only.
4) If Rx is in DVB-S2 mode, the Rx Modulation Type and FEC rate are
ignored because these are automatically detected.
9–25
Description of Arguments
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
TRC= TRC=
TRC? aaaa.aaaabcc.cc
TRC* ccccdefghhhhhh
TRC# iii.ijkllll.llllmnn.n
nnnnnopqxsssss
stuvv
