CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
Boot Image IMG= IMG?
Management IPA= IPA?
IP Address
Gateway IP IPG= IPG?
Address
Interface N/A ITF?s
Type
Rx Link N/A LNK?
Margin
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
1 byte Command only.
Selects the Boot image in the form n where:
n=FW Image 1 or 2
COMMAND EXAMPLE: <0001/IMG=1{CR} (sets Image 1 for bootup)
18 bytes Command or Query.
Sets or returns the Management IP Address and Subnet Mask for the 10/100
BaseT 'J4 | Ethernet' management port, in the form xxx.xxx.xxx.xxx.yy where:
xxx.xxx.xxx.xxx=IP Address
yy=Subnet Mask (00 to 31)
COMMAND EXAMPLE: <0001/IPA=010.006.030.001.24{CR}
15 bytes Command or Query.
Sets or returns the Gateway IP Address for the 10/100 BaseT 'J4 | Ethernet'
management port in the form xxx.xxx.xxx.xxx where:
xxx.xxx.xxx.xxx=IP Address
COMMAND EXAMPLE: <0001/IPG=010.006.030.001{CR}
2 bytes Query only.
Returns Interface Type in the form in response to query 's' where:
s=Interface Slot 1 or 2
QUERY EXAMPLE: <0001/ITF?1{CR}
>0001/ITF=1x{CR}{LF} where x=active interface type:
0=CDI-40 ASI (Interface Slot 1 only)
1=CDI-70 GBEI (Interface Slot 2 only)
2=CDI-60 HSSI (Interface Slot 1 only)
4 bytes Query only.
Returns the value of the Link Margin in the form xx.x.
NOTE: Returns 00.0 if demod is unlocked.
EXAMPLE: <0001/LNK?{CR}
>0000/LNK=12.3{CR}{LF}
9–36
Description of Arguments
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
IMG= IMG=n
IMG?
IMG*
IMG#
IPA= IPA=xxx.xxx.xxx.
IPA? xxx.yy
IPA*
IPA#
IPG= IPG=xxx.xxx.xxx.
IPG? xxx
IPG*
IPG#
ITF? ITF=sx
ITF*
ITF#
LNK? LNK=xx.x
LNK*
LNK#
