Comtech EF Data CDM-710 Installation And Operation Manual page 246

CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
Rx Alpha RAR= RAR?
Rolloff
Rx Buffer Size RBS= RBS?s
Soft Reboot RBT=1 N/A
Rx Clock RCI= RCI?s
Inverted
Rx Clock RCK= RCK?s
Source
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
1 byte Command or Query.
Sets or returns the Rx Alpha Rolloff in the form x where:
0=20%
1=25%
2=35%
COMMAND EXAMPLE: <0001/RAR=0{CR} (sets Rx Alpha Rolloff to 20%)
5 bytes Command or Query.
Sets or returns the Rx Buffer Size, in milliseconds, in the form sxx.x where:
s=1 (Interface Slot 1 only)
xx.x=Rx Buffer Size for HSSI value from 5.0 to 32.0 ms, in 0.1 ms steps
NOTE: Valid for Slot 1 CDI=-60 HSSI operation only. Not valid for Slot 1 CDI-40
ASI operation, or Slot 2 CDI-70 GBEI operation.
COMMAND EXAMPLE: <0001/RBS=130.0{CR} (sets 30.0 ms on Intfc #1)
1 byte Command only.
Executes a soft reboot of the unit in the form x where:
1=Reboot System
EXAMPLE: <0001/RET=1{CR}
2 bytes Command or Query.
Sets or returns CDI-60 HSSI Inverted Rx Clock in the form sx where:
s=1 (Interface Slot 1 only)
x=CDI-60 HSSI Inverted Rx Clock where 0=Normal, 1=Inverted
NOTE: Not valid for Slot 1 CDI-40 ASI or Slot 2 CDI-70 GBEI operation.
2 bytes Command or Query.
Sets or returns CDI-60 HSSI Rx Clock Source (for data rate accuracy) in the
form sx, where:
s=1 (Interface Slot 1 only)
x=Rx Clock Source where 0=Rx Satellite, 1=Tx-Terrestrial, 2=External
Reference Clock, 3=Internal
NOTE: Not valid for Slot 1 CDI-40 ASI or Slot 2 CDI=70 GBEI operation.
COMMAND EXAMPLE: <0001/RCK=11{CR} (sets Tx-Terrestrial)
