ENGINE CONTROL TROUBLE CODE
Blink code EFI warning
lamp (MIL)
Display on diagnostic tool
Error level condition
Function check
Possible cause
Last measure if none of the doc-
umented causes leads to elimi-
nation of the fault
Ambient air pressure sensor - checking the voltage
Condition
The ignition is on.
The diagnostic tool is connected and running.
The engine is switched off.
–
Select the model.
–
Select "ECU Diagnosis".
–
Mark the "Engine management EFI LC8 RC8" control unit.
–
Press "Continue".
–
Select "Measured Values".
–
Highlight "Fuel management general".
–
Press "Continue".
–
Highlight "Ambient air pressure sensor voltage (PAAD)" and deselect the other parameters with "Select live data".
Ambient air pressure sensor voltage "PAAD"
at: 800 mbar (11.6 psi)
at: 850 mbar (12.33 psi)
at: 900 mbar (13.05 psi)
at: 950 mbar (13.78 psi)
at: 1,000 mbar (14.5 psi)
at: 1,050 mbar (15.23 psi)
» If the displayed value corresponds to the nominal value:
–
Delete trouble code.
–
Take a test ride.
–
Read out the trouble code memory using the KTM diagnostics tool.
» If the displayed value is below the nominal value:
–
Check the next possible cause:
Ambient air pressure sensor - the signal wire has a short circuit to sensor ground (
Ambient air pressure sensor - the signal wire has a short circuit to sensor ground
14 EFI warning lamp (MIL) flashes 1x long, 4x short
P1107
"Ambient air pressure sensor "
"Input signal too low"
Ambient air pressure sensor voltage "PAAD": ≤ 0.508 V
Time: ≥ 3 s
Substitute value: 970 mbar (14.07 psi)
Ambient air pressure sensor - checking the voltage (
Ambient air pressure sensor - the signal wire has a short circuit to sensor ground (
Ambient air pressure sensor - the signal wire has a short circuit to ground (terminal 31)
( p. 349)
Ambient air pressure sensor - the power supply is interrupted (
–
Change the ambient air pressure sensor.
Condition
The ignition is off.
The EFI control unit is disconnected. (
The ambient air pressure sensor is disconnected. (
p. 348)
2.97... 3.03 V
3.12... 3.18 V
3.27... 3.33 V
3.42... 3.48 V
3.57... 3.63 V
3.72... 3.78 V
p. 348)
p. 227)
p. 348)
p. 349)
p. 225)
