4
Customising Settings for Your Home
<Room sensor settings>
For room sensor settings it is important to choose the correct room sensor de-
pending on the heating mode the system will operate in.
1. From the Initial settings menu select Room sensor settings.
2. When 2-zone temperature control is active or wireless remote controllers are
available, from Room RC zone select screen, select zone no. to assign to
each remote controller.
3. From Sensor setting screen, select a room sensor to be used for monitoring
the room temperature from Zone1 and Zone2 separately.
Control option
Corresponding initial settings room sensor
("Remote Controller Options"
(Installation manual))
A
Room RC1-8 (one each
for Zone1 and Zone2)
B
C
D
*  Notspecified(ifafield-suppliedroomthermostatisused)
Room RC1-8 (one each for Zone1 and Zone2) (if a wireless remote controller
is used as a room thermostat)
4. From Sensor setting screen, select Time/Zone to make it possible to use differ-
ent room sensors according to the time schedule set in the Select Time/Zone
menu. The room sensors can be switched up to 4 times within 24 hours.
Zone1
Zone2
*
TH1
*
Main controller
*
*
*
Time/Zone schedule setting screen
10
