SLM-7650 Satellite Modem
Operation
3.4.5
Remote AUPC Menu
This menu will only be displayed if the modem is programmed to a mode that allows
AUPC functionality. Within the Utility Modem Type menu, selection of Modem Types
7650-02 or ASYNC will activate this display.
Note:
The remote functions may be viewed or changed by entering the Remote AUPC level
from the Function select menu on the front panel After entering the Remote AUPC menu,
press [←] or [→] to select the Configuration or Monitor menu. Enter the selected menu
by pressing [ENTER]. Press [←] or [→] to view the selected configuration parameters.
3.4.5.1
Remote AUPC Configuration
Menu Item
AUPC ENABLE
B-BAND LOOP BACK
TX 2047 PATTERN
3.4.5.2
Remote AUPC Monitor
Menu Item
2047 ERRORS
These are extra configuration commands that can modify the distant end
modem. These configuration or monitor functions can only be accomplished if
the modems are locked under the configuration of 7650-02 or ASYNC as a
modem type.
Programs the AUPC enable On or Off.
On entry, the current status of the remote AUPC is displayed. Press an arrow key
to make the selection. Press [ENTER] to execute the change.
Note: This program is for control or last known status.
Programs the remote baseband loopback On or Off.
On entry, the current status of the remote baseband loopback is displayed. Press
an arrow key to make the selection. Press [ENTER] to execute the change.
Note: This program is for control or last known status.
Programs the remote TX 2047 pattern On or Off.
On entry, the current status of the remote TX 2047 is displayed. Press an arrow
key to make the selection. Press [ENTER] to execute the change.
Note: This program is for control or last known status.
Receive 2047 BER. This is a monitor point that displays the current distant
end RX 2047 BER. If no data is available, "No Data" is displayed.
Specifications/usage
Specifications/usage
3-26
Revision 4
MN/SLM7650.IOM
