CDM-700 High Speed Satellite Modem
Front Panel Operation

6.3.1 (SELECT:) CONFIG

CONFIG: Remote Tx
Intfc1
The submenus available are:
Selection
Remote
Tx
Rx
Intfc1
or
Intfc2
Ref
Aux
The modem may be monitored over the remote control bus at any time. When
in Local mode, however, configuration parameters may only be changed
through the front panel. Conversely, when in Remote mode, the unit may be
monitored from the front panel, but configuration parameters may only be
IMPORTANT
changed via the remote control bus.
Rx
Intfc2 Ref Aux
Submenu Description
[Remote Control] - used to define whether the unit is controlled locally or
remotely. (See Important Note.)
[Transmit] - used to define, on a parameter-by-parameter basis, the Tx
configuration of the unit. These submenu branches would be used to
change, for example, just the Tx Frequency.
[Receive] - used to define, on a parameter-by-parameter basis, the Rx
configuration of the unit. These submenu branches would be used to
change, for example, just the Rx Frequency.
[Interface] - used to configure Interfaces plugged into Slot 1 or Slot 2 on
the back of the unit. The menus change depending on the type of
interface – as of this manual revision, Dual E3/T3/STS-1, Dual G.703,
OC3, HSSI, and Gigabit Ethernet (GbE) are available.
[Reference] - used to configure the source of the modem reference
frequency.
[Auxiliary] - used to enable Redundancy. In 1:1 operation, allows the
online unit to force switchover.
6–7
Revision 5
MN/CDM700.IOM
