4400 Bar Code Label Printer User's Manual
3. Press [SELECT]. Then press [ ] or [ ] until the display shows the following:
4. Press [SELECT]. The display shows the current Security level with an
5. Press [ ] or [ ] until you see the security level you want, and then press
6. Press [CONTINUE] to return to the OFFLINE READY display.

Bypassing Security Levels

You can bypass a security level if you need to access a restricted menu from the
control panel.
To bypass a security level
1. Turn the printer off.
2. Hold down the [FEED/RELOAD] key while you turn the printer on.
This procedure sets security level 0, which allows access to all menus.

Cloning

Cloning is the process of copying the RAM contents from one printer (the
sender printer) to another printer (the receiver printer). By programming and
configuring just one printer and then cloning its RAM to other printers, you
can configure a large number of printers in much less time than it would take
to program them individually.
The clone command copies the following RAM contents to the receiver printer:
The cloning procedure consists of connecting the main serial ports of two
printers together with an RS-232 null modem cable. Control panel commands
are then used to designate each printer as either a sender or receiver. The
control panel on the sender printer is used to execute the clone command.
8-4
INSTALL MENU
SECURITY
asterisk (*) such as in the example below:
SECURITY
LEVEL 0*
[ENTER] to move the asterisk (*) to that level as in the example below:
SECURITY
LEVEL 1*
Printer configuration data
Label formats, page formats, fonts, graphics and User-Defined protocol or
command tables
