  • Page 1 Instruction Sheet P/N 070872-001 Centronics Parallel I/O Card...
  • Page 2 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
  • Page 3 The following instructions explain how to install an Intermec Centronics Parallel I/O Card into Intermec 3240, 3400, 3440, 3600, and 4400 printers. This procedure is to be performed by trained Intermec service personnel only. Centronics Parallel I/O Card Ribbon cable...
  • Page 4 Before opening the bag, touch it to the metal base of the printer to reduce static electricity. Touch the metal base of the printer to reduce static electricity before installing the parallel I/O card in the printer.
  • Page 5 Ribbon cable Main PCB 5. With the component side of the parallel I/O card facing the interior of the printer, secure the parallel I/O card to the optional I/O board port with the two port cover screws. Ribbon cable...
  • Page 6 7. Reinstall and secure the media cover and electronics cover. 8. Reinstall the power cord. 9. Test that the printer recognizes the parallel I/O card by printing a hardware configuration test label. See the printer user’s manual for instructions on printing a hardware configuration test label.
  • Page 7 I/O card in the printer. 1. Turn off the printer power and remove the power cord. 2. Open the tower door by removing the three Phillips screws at the rear of the printer (see illustration). 3. Remove and discard the port cover from the optional I/O board port. Retain the two screws.
  • Page 8 TTR assembly. Close the tower door and secure it with three Phillips screws. 8. Test that the printer recognizes the parallel I/O card by printing a hardware configuration test label. For help, see the 4400 User's Manual (Part No. 058607).
