5
Create Ladder
Programming.
Special Instructions
Write related
Auxiliary Area bits.
Read related
Auxiliary Area bits.
6
Transfer the PLC
Setup and ladder
programs.
7
Restart the CJ2M
PLC.
8
Start operation.
CJ2M CPU Unit Pulse I/O Module User's Manual
2 I/O Application Procedures and Function Allocations
Write ladder programs using the CX-Pro-
grammer.
Example: Enable interrupts with the
MSKS(690) instruction and program high-
speed counters with the CTBL(882) instruc-
tion.
Example: Resetting a high-speed counter.
Example: Reading the present value of a
high-speed counter.
Transfer the PLC Setup and ladder programs
from the CX-Programmer to the CJ2M CPU
Unit.
Turn OFF the power supply to the CJ2M
PLC, then turn it ON again.
Start the operation of the CJ2M CPU Unit.
Refer to the informa-
tion on the Auxiliary
2
Area in the CJ2 CPU
Unit Software User's
Manual (Cat. No.
W473).
2-3
