A-3 Comparison to CJ1M Built-in I/O
Functions
Normal inputs
Differ-
ences in
operation
Normal outputs
Quick-response
inputs
Interrupt Inputs
Differ-
ences in
operation
CJ2M CPU Unit Pulse I/O Module User's Manual
Item
CJ2M with Pulse I/O Module
20 inputs (10 × 2 Pulse I/O Modules)
Number of inputs
Input response time ON response time: 8 ms max.
OFF response time: 8 ms max.
Update timing for PLC Update timing for input constants:
Setup When power is turned ON
12 outputs (6 × 2 Pulse I/O Modules)
Number of outputs
Output response time ON response time: 0.1 ms max.
OFF response time: 0.1 ms max.
Maximum switching 4.75 to 26.4 VDC
capacity
0.3 A/output; 1.8 A/Unit
Output type Sinking (CJ2M-MD211)
Sourcing (CJ2M-MD212)
8 inputs (4 × 2 Pulse I/O Modules)
Number of inputs
30 µs
Minimum pulse width
8 inputs (4 × 2 Pulse I/O Modules)
Number of inputs
ON response time: 30 µs max.
Input response time
OFF response time: 150 µs max.
Interrupt modes Direct Mode and Counter Mode
Software latching for Supported.
PVs of high-speed
counters and pulse
outputs when an inter-
rupt occurs
Update method for Updating interrupt counter SV in Auxil-
interrupt counter SV iary Area and then executing
(Counter Mode) MSKS(690) again to enable interrupts
Update method for INI(880) instruction
interrupt counter PV
(Counter Mode)
Update timing for • Every cycle
interrupt counter PV
• When count completion interrupt
(Counter Mode)
occurs
• When PRV(881) instruction is exe-
cuted
Operation of interrupt Counter operation continued, but inter-
counters when inter- rupt will not occur at count completion
rupts are disabled with
DI(693)
Specification/performance
CJ1M built-in I/O
10 inputs
ON response time: 8 ms max.
OFF response time: 8 ms max.
Update timing for input constants:
When operation is started
6 outputs
ON response time: 0.1 ms max.
OFF response time: 0.1 ms max.
4.75 to 26.4 VDC
0.3 A/output; 1.8 A/Unit
Sinking
4 inputs
30 µs
4 inputs
ON response time: 30 µs max.
OFF response time: 150 µs max.
Direct Mode and Counter Mode
Not supported.
Updating interrupt counter SV in Auxil-
iary Area
• INI(880) instruction
• Updating interrupt counter PV in Aux-
iliary Area
• Once per count
• When PRV(881) instruction is exe-
cuted
Counter operation not continued.
