21
Configuring numbered and named ACLs
The <string> parameter is the ACL name. You can specify a string of up to 256 alphanumeric
characters. You can use blanks in the ACL name if you enclose the name in quotation marks (for
example, "ACL for Net1"). The <num> parameter allows you to specify an ACL number if you prefer.
If you specify a number, you can specify from 1 – 99 for standard ACLs or 100 – 199 for extended
ACLs.
NOTE
For convenience, the software allows you to configure numbered ACLs using the syntax for named
ACLs. The software also still supports the older syntax for numbered ACLs. Although the software
allows both methods for configuring numbered ACLs, numbered ACLs are always formatted in the
startup-config and running-config files in using the older syntax, as follows.
access-list 1 deny host 209.157.22.26 log
access-list 1 deny 209.157.22.0 0.0.0.255 log
access-list 1 permit any
access-list 101 deny tcp any any eq http log
The options at the ACL configuration level and the syntax for the ip access-group command are the
same for numbered and named ACLs and are described in
on page 518.
Configuration example for extended ACL
To configure a named extended ACL entry, enter commands such as the following.
BigIron RX(config)# ip access-list extended "block Telnet"
BigIron RX(config-ext-nacl)# deny tcp host 209.157.22.26 any eq telnet log
BigIron RX(config-ext-nacl)# permit ip any any
BigIron RX(config-ext-nacl)# exit
BigIron RX(config)# int eth 1/1
BigIron RX(config-if-e10000-1/1)# ip access-group "block Telnet" in
Syntax: [no] ip access-list extended <string> | <num> deny | permit <ip-protocol>
The 16 x 10 GE module only supports the following extended named ACLs.
Syntax: [no] ip access-list extended<string> | <num> deny | permit <ip-protocol>
530
<source-ip> | <hostname> <wildcard>
[<operator> <source-tcp/udp-port>]
<destination-ip> | <hostname> <wildcard>
[<operator> <destination-tcp/udp-port>]
[match-all <tcp-flags>] [match-any <tcp-flags>]
[<icmp-type>] [established] [precedence <name> | <num>]
[tos <number>] [dscp-matching <number>]
[802.1p-priority-matching <number>]
[dscp-marking <number> 802.1p-priority-marking <number> internal-priority-marking
<number>]
[dscp-marking <number> dscp-cos-mapping]
[dscp-cos-mapping]
[fragment] [non-fragment] [first-fragment]
[fragment-offset <number>]
[spi <00000000 - ffffffff>] [log]
<source-ip> | <hostname> <wildcard>
[<operator> <source-tcp/udp-port>]
<destination-ip> | <hostname> <wildcard>
[<operator> <destination-tcp/udp-port>]
"Configuring standard numbered ACLs"
