Module Cam Lever–HP-qualified personnel only
To replace the module cam lever (see
1. Observe the module cam lever is guided by a locking bracket that fits into a track. Notice the track has
a notch observable when the lever is fully out
2. Remove the lever by squeezing the tabs of the pivot and lifting the lever away from the module.
3. Position the lever locking bracket over the track notch (observed in step 1), and lift it from the track.
4. To replace, insert the cam lever locking bracket into the track at the notched area, then snap the cam
lever onto the pivot point.
Module Cam Lever–HP-qualified personnel only
Figure 35):
(Figure 35).
Removal and Replacement
203
