Product Description
Product Features
Product Features
Figure 2
shows the front of the disk array.
Figure 3
shows the rear of the disk array.
Figure 4
shows the controls and indicators on the disk array.
Figure 5
shows the slot numbers for the disk modules.
1 – Power/Standby Switch
16
Figure 2. Disk Array Front Panel
2 – Control Panel Display
3 – Control Panel Status Light
