Troubleshooting
Control Panel Error Messages
Control Panel Error Messages
The control panel is capable of displaying error messages, which indicate possible disk array failures.
Different types of errors may be displayed, such as System States, Disk States, and other errors.
Table 10
shows all possible errors regarding System States.
Table 11
shows all possible errors regarding
Disk States.
Table 12
shows the remaining control panel error messages listed alphabetically. Each table
shows the control panel error message, an explanation of the error, and the action that should be taken to
resolve the problem.
NOTE! The letter "x" or "y" that is displayed on the right side of the display panel usually
indicates which array controller is set as the primary array controller. If there is a controller fault, it
does not indicate the faulty controller.
123
