FRU Codes

Each replaceable hardware assembly in the disk array is assigned a FRU (Field Replaceable Unit) code.
These FRU codes are used to identify suspect hardware in the controller event logs. Table 13 lists the FRU
codes and the hardware assembly associated with each.
FRU Code
0
1
2
3
4
5
6
7
8
9
10
11
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
192
193
194
195
1
The reporting controller is the controller identified in the Component Specific ID field of the Controller
Error Event specific data.
Table 13 Disk Array FRU Codes
Hardware Assembly
Disk in slot A1
Disk in slot B1
Disk in slot A2
Disk in slot B2
Disk in slot A3
Disk in slot B3
Disk in slot A4
Disk in slot B4
Disk in slot A5
Disk in slot B5
Disk in slot A6
Disk in slot B6
Reporting Controller 1 , or No FRU.
First installable SIMM on X controller
Second installable SIMM on X controller
First installable SIMM on Y controller
Second installable SIMM on Y controller
2
Other (non-reporting ) controller
Battery
Fan 1
Fan 2
Fan 3
Power Supply 1
Power Supply 2
Controller X
Controller Y
Power Supply 3
Internal SCSI Bus 0
Internal SCSI Bus 1
Internal SCSI Bus 2
Internal SCSI Bus 3
