AC Power Receptacle–HP-qualified personnel only
CAUTION! The following procedures require that you perform a shutdown, turn off the
disk array, and make it inaccessible. Check with the system administrator before
proceeding.
To replace the ac power receptacle
1. Remove appropriate power module and its power cord.
2. Remove the two T-15 screws (2) from the ac power receptacle. Remove the ac power receptacle. Be
careful not to drop the screws into the chassis, since they are difficult to locate if they fall below the
chassis tray.
3. Replace in reverse order, ensuring that the metal spacer is inserted between the ac power receptacle
and the back of the chassis. Also, make sure that the larger end of the ac power receptacle is installed
toward the outside of the chassis, and that the ground pin on the ac power receptacle is facing upward.
AC Power Receptacle–HP-qualified personnel only
(Figure 34, Item 1):
Removal and Replacement
201
