Wind Direction - Simrad SX90 - REFERENCE MANUAL REV D Reference Manual

Simrad SX90
180

Wind Direction

The parameter dialog opens when you click the
Wind Direction
button in the
Wind Direction
The wind marker is shown as a white arrow in the outer area of
the echo presentation. This arrow can be manually adjusted for
indication of the wind or current direction, or automatically show
the wind direction if a wind sensor is connected.
Options
+ (plus): Click to increase the wind direction.
– (minus): Click to decrease wind direction.
: Click to enable manual setting of the wind direction.
Manual
: Click to enable automatic setting of the wind direction.
Auto
The information must then be provided from an external sensor
connected to the sonar.
: Click to close the parameter dialog.
Close
: Click to access the on-line help.
Help
Related topics
Setup menu on page 89
menu.
Setup
