GeoView menu

Menu description
Menu buttons
• : Click this button to move the ship symbol to
Ship to centre
the centre of the view.
• : Click this button to select the scale of the horizontal
Scale
presentation. 100% is the default scale. (► Scale on page 155)
• : This button is used to show the movement
Target Track
history of a selected target. The history is displayed as a line
after the target symbol. Straight line segments are drawn
between each position fix, and minute markers may be added
along the line. (► Target Track on page 167)
The menu is activated by
GeoView
pressing the button on the Operating
View
Panel or the middle mouse button in any
horizontal view, and then selecting
in the pop-up.
Menu View
The menu provides control of
GeoView
selected parameters related to the current
data displayed in the horizontal view; the
scale and target track. It also provides
you with a button to reposition the vessel
symbol. The
GeoView2
to the . It is shown when you
GeoView
operate in the second view in a Dual 1 or
Dual 2 operational modes.
• The button opens the on-line
Help
help.
• The button closes this menu.
Close
Menu descriptions
View
menu is identical
