Direction Indicator

The
Direction Indicator
the
Direction Indicator
that must be set to Indicator in order to access this
Data Source
parameter.
The menu is activated by pressing the
VerticalView
on the Operating Panel (or the middle mouse button) while
positioning the cursor in any of the vertical views, and then
selecting
View menu
This feature allows you to train the vertical slices independent
of the audio channel. The Direction Indicator is shown in the
horizontal presentation as a yellow dotted line.
The following options are available in the
parameter dialog:
• + (plus): Click to increase the direction angle with one degree.
• – (minus): Click to decrease the direction angle with one
degree.
• : Click to close the parameter dialog.
Close
• : Click to access the on-line help.
Help
Related topics
Setup menu on page 89
Data Source on page 120
parameter dialog opens when you click
button in the
VerticalView
on the pop-up.
View
menu. Note
button
View
Direction Indicator
