Simrad SH90
174
•
Save Current Settings
used parameter settings. You will always save your current
setting as a "new user". By default the setting will be named
User N, and "N" is simply the next available number.
Note
In principles you can use any name, but the
the Operating Panel will only choose from User 1, User 2,
User 3 and User 4. These names must also be on the top of
the list. If you wish to add users, apply names like for example
"User 5 Charlie".
• : Click to select one of the settings in the list, then click
Delete
this button to delete it.
• : This option provides an on-screen keyboard to
Rename
rename the stored user setting. Click on a setting to select it,
then click this button. Enter the new name using the on-screen
keyboard.
• : By means of the four
Select users
Operating Panel you can select the four top users on the list.
The list of users is sorted alphabetically, and you can rename
the users and thus control which
user.
• : Click to close the parameter dialog.
Close
• : Click to access the on-line help.
Help
Related topics
• User setting procedures on page 57
• Setup menu on page 98

Wind Direction

Dialog description
The parameter dialog opens when you click the
Wind Direction
button in the
Wind Direction
The wind marker is shown as a white arrow in the outer area of
the echo presentation. This arrow can be manually adjusted for
indication of the wind or current direction, or automatically show
the wind direction if a wind sensor is connected.
: Use this option to save all the currently
buttons on the
Mode
button to recall which
Mode
menu.
Setup
buttons on
Mode
