Automatic search and tracking procedures

50
Note
This procedure assumes that you have basic knowledge of file
management in Windows.
1 Insert a USB memory stick into the Processor Unit.
2 Observe that the operating system's auto-start function
opens a dialog requesting guidance.
3 Select
Open Windows Explorer
4 Observe that a
Windows Explorer
5 By means of normal Windows functions, navigate to the
folder d:/winson/screendumps.
6 Double-click to open sub-folder Permanent or Temporary.
7 Click to select the images you wish to copy to the USB
memory stick, and copy them to the USB's
window.
Explorer
8 Remove the USB memory stick, and close the
window.
Explorer
To access the operating system functions, you can click any
button. When the help window opens, you can also access the
with the
Taskbar Start
The SX90 sonar provides you with two automatic search
programs, horizontal and vertical. Both are initiated from the
Operating Unit

How to start the horizontal search program

Observe the following procedure to run the automatic search
program.
Procedure
1 Press the
Auto search
Operating Panel to start the horizontal search program.
, and click
window opens.
button.
button in the
Train
.
OK
Windows
Windows
Help
field on the
