Range (Catchview) - Simrad SX90 - REFERENCE MANUAL REV D Reference Manual

Simrad SX90
150

Range (CatchView)

The
Range (CatchView)
the button in the
Range
is in turn activated by pressing the
Panel (or the middle mouse button), while the cursor is located
in the Catch view, and then selecting
pop-up menu.
This parameter dialog is used to select the range in the Catch
view. You can define the range manually, or select automatic
setting. The CatchView range will then follow the range currently
selected for the other vertical views.
Options
: Click to select manual range.
[Range]
: Click to enable manual range selection.
Manual
: Click to enable automatic range selection. The range will
Auto
then follow the range currently selected for the other vertical
views.
: Click to close the parameter dialog.
Close
: Click to access the on-line help.
Help
Related topics
Operating Panel 'Cursor' field on page 76
CatchView menu on page 103
Range on page 149
parameter dialog opens when you click
menu. The
CatchView
button on the Operating
View
View menu
menu
CatchView
on the
View
307670/D
