Parameters
•
Set New Display Centre
new display centre is moved to the cursor's position where
the menu was activated.
View
• : When this function is selected, the own ship
Ship To Centre
symbol is moved to the centre of the view.
• : The zoom function magnifies an area of the display
Zoom
by positioning the cursor in its centre and pressing the
button. The
Zoom
of the zoom function.
• : When this function is selected, all echoes
Erase Echoes
displayed on the sonar view will be deleted.
• - This function is not operational on the sonar.
Synchronize
For synchronization to external equipment, refer to the
menu.
• : When this function is selected, window areas
Make Same Size
tiled vertically will acquire the same width.
• : This command changes the display from
Grey scale data
a colour presentation to a black-and-white. The number of
shades of grey and the number of different colours used will
be the same. The grey scale presentation can be selected for
singular sonar views independent of each other. Click one
more time to restore the colours.
• : When this function is selected menus will be
View Menu
displayed according to the view in which the cursor is situated.
Several different
View

Catch View pop-up menu

The pop-up menu is accessed by pressing the
Catch View
button on the Operating Panel (or the middle mouse button) when
the cursor is located in a Catch Data view.
: When this function is selected, the
button works as a toggle switch for on/off
menus are available.
Zoom
Setup
View
