OPERATIONAL PROCEDURES

Power on/off procedures

34
This chapter presents how to perform the most common
procedures on the SX90 sonar. Note that the power on/off
procedures have been previously explained.
Topics
• Power on/off procedures on page 34
• Menu procedures on page 36
• Gain adjustment procedures on page 37
• Mode procedures on page 39
• Markers and symbols procedures on page 41
• Storage procedures on page 45
• Automatic search and tracking procedures on page 50
• User setting procedures on page 53
• Installation of options on page 56
These procedures explain how to switch the sonar system on
and off.
Related topics
• TRU On/Off on page 173
How to switch on the sonar
1 Press the button on the colour display monitor.
Power
2 Press the button on the Operating Panel, and keep it
Power
depressed for approximately two seconds.
• The green lamp on the right side of the button will flash
to indicated that the power has been switched on, and that
the computer is starting up.
• After a few seconds the Processor Unit starts up. Once
up and running, it automatically starts the Beamformer
Unit. You can observe the progress on the
dialog boxes that appear.
• After a short period (approximately 2 minutes) you will
see the sonar picture on the display.
3 Check that the water depth beneath the keel is sufficient to
lower the transducer.
TRU On/Off
