Simrad SX90
182

Zoom Scale

The
parameter dialog opens when you click the
Zoom
button in the
VerticalView
This parameter dialog is used for scaling the zoom around the
bottom.
The following options are available in the
dialog:
•
: Click to select zoom scale.
[x] %
•
: Click to close the parameter dialog.
Close
•
: Click to access the on-line help.
Help
Related topics
VerticalView menu on page 102
menu.
Zoom Scale
Zoom
parameter
307670/D
