Edit Gear (Purse)

The parameter dialog opens when you click the
Gear
on the menu. Each of the available options in the
Setup
dialog can be edited using the
been selected, this
Edit Gear
These parameters allows you to define the depth and the length
of your purse seine, as well as which side of the vessel it is
positioned.
Options
: Click to enter the depth of your purse seine. When the
Depth
symbol is selected, the depth of the purse seine will be
Gear
shown on all vertical views.
: Click to enter the length of your purse seine. When the
Length
symbol is selected, the seine circle will be shown in correct
Gear
size. A dedicated parameter dialog is used to make this setting.
: Click to position the seine circle on the port or
Throw Side
starboard side of the vessel. A dedicated parameter dialog is used
to make this setting.
: Click to close the parameter dialog.
Close
: Click to access the on-line help.
Help
Related topics
Setup menu on page 89
Gear on page 133
button. When a purse has
Edit
parameter dialog is provided.
button
Gear
Gear
